135 5xD
FRACTIONAL & METRIC SERIES
CUTTING
DIAMETER
D
1
DECIMAL
EQUIV.
METRIC
EQUIV.
TAP SIZE
REFERENCE
ONLY
SHANK
DIAMETER
D
2
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
CLEARED
LENGTH
L
3
SHANK
LENGTH
L
4
Ti-NAMITE-A
(AlTiN)
EDP NO.
1/64 0.0156 0.40
1/8
1 1/2 5/32 7/64
1
52300*
1/32 0.0312 0.79
1/8
1 1/2 5/16 7/32
1
52301*
3/64 0.0469 1.19
1/16-64
1/8
1 1/2 25/64 19/64
1
52302*
1,25 mm 0.0492
3,0
38,0
10,0
7,5
25,0
64520*
1,45 mm 0.0571
3,0
38,0
10,0
7,5
25,0
64521*
#53 0.0595 1.51
1/8 1-1/2 25/64 19/64
1
64522*
1/16 0.0625 1.59
5/64-60
1/8
2
15/32 23/64 1-1/4
52303*
1,6 mm 0.0630
3,0
50,0
12,0
9,0
32,0
64523*
1,75 mm 0.0689
3,0
50,0
12,0
9,0
32,0
64524*
#50 0.0700 1.78
1/8
2
15/32 23/64 1-1/4
64525*
5/64 0.0781 1.98
1/8
2
35/64 27/64 1-1/4
52304*
#47 0.0785 1.99
1/8
2
35/64 27/64 1-1/4
64526*
2,05 mm 0.0807
3,0
50,0
14,0
11,0
32,0
64527*
#46 0.0810 2.06
1/8
2
35/64 27/64 1-1/4
64528*
#43 0.0890 2.26
1/8
2
19/32 15/32 1-1/4
64529*
#42 0.0935 2.37
1/8
2
5/8
1/2
1-1/4
64530*
3/32 0.0938 2.38
1/8-32
1/8
2
5/8
1/2
1-1/4
52305
#40 0.0980 2.49
1/8
2
43/64 17/32 1-1/4
52306
2,5 mm 0.0984
3,0
50,0
17,0
13,0
32,0
64531
#39 0.0995 2.53
1/8
2
43/64 17/32 1-1/4
52307
#38 0.1015 2.58
5-40
1/8
2
43/64 17/32 1-1/4
52308
#37 0.1040 2.64
5-44
1/8
2
45/64 9/16 1-1/4
52309
#36 0.1065 2.71
6-32
1/8
2
45/64 9/16 1-1/4
52310
7/64 0.1094 2.78
1/8
2
3/4 19/32 1-1/4
52311
#35 0.1100 2.79
1/8
2
3/4 19/32 1-1/4
52312
#34 0.1110 2.82
1/8
2
3/4 19/32 1-1/4
52313
#33 0.1130 2.87
6-40
1/8
2
3/4 19/32 1-1/4
52314
2,9 mm 0.1142
3,0
50,0
19,0
15,0
32,0
64532
#32 0.1160 2.95
1/8
2
3/4 39/64 1-1/4
52315
3,0 mm 0.1181
6,0
66,0
28,0
23,0
36,0
64100
#31 0.1200 3.05
1/8
2
3/4 39/64 1-1/4
52316
3,1 mm 0.1220
6,0
66,0
28,0
23,0
36,0
64101
1/8 0.1250 3.18
1/4
3
1
53/64 1-7/16
51580
3,2 mm 0.1260
M3,5 X 0,35
6,0
66,0
28,0
23,0
36,0
64102
#30 0.1285 3.26
1/4
3
1
53/64 1-7/16
51581
3,3 mm 0.1299
M4 X 0,7
6,0
66,0
28,0
23,0
36,0
64103
3,4 mm 0.1339
8-32,8-36
6,0
66,0
28,0
23,0
36,0
64104
#29 0.1360 3.45
1/4
3
1
53/64 1-7/16
51582
continued on next page
FRACTIONAL & METRIC
Hi-PerCarb
2
• Double margin design
improves accuracy and
surface finish along with
increased strength for
aggressive drilling
• Specialized self-
centering notched point
eliminates the need for
spot drilling decreasing
thrust and deflection
• Engineered edge
protection improves edge
strength and reduces
edge fatigue allowing for
increased feed rates
• Recommended for
materials ≤ 56 HRc
(≤ 577 Bhn)
*Single Margin
TOLERANCES
(mm)
≤3
DIAMETER
D
1
=
+0,002/+0,012
D
2
=
h
6
>3–6
DIAMETER
D
1
=
+0,004/+0,016
D
2
=
h
6
>6–10
DIAMETER
D
1
=
+0,006/+0,021
D
2
=
h
6
>10–18
DIAMETER
D
1
=
+0,007/+0,025
D
2
=
h
6
>18–30
DIAMETER
D
1
=
+0,008/+0,029
D
2
=
h
6
TOLERANCES
(inch)
≤.1181
DIAMETER
D
1
=
+.00008/+.00047
D
2
=
h
6
>.1181–.2362
DIAMETER
D
1
=
+.00016/+.00063
D
2
=
h
6
>.2362–.3937
DIAMETER
D
1
=
+.00024/+.00083
D
2
=
h
6
>.3937–.7087
DIAMETER
D
1
=
+.00028/+.00098
D
2
=
h
6
>.7087–1.1811
DIAMETER
D
1
=
+.00031/+.00114
D
2
=
h
6
For patent
information visit
www.ksptpatents.com
