255 / 396
DRILLS
DRILLS
255
www.kyocera-sgstool.com
CUTTING
DIAMETER
D
1
DECIMAL
EQUIV.
METRIC
EQUIV.
TAP SIZE
REFERENCE
ONLY
SHANK
DIAMETER
D
2
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
CLEARED
LENGTH
L
3
SHANK
LENGTH
L
4
Ti-NAMITE-A
(AlTiN)
EDP NO.
3,5 mm 0.1378
6,0
66,0
28,0
23,0
36,0
64105
#28 0.1405 3.57
8-40
1/4
3
1
53/64 1- 7/16
52317
9/64 0.1406 3.57
1/4
3
1
53/64 1-7/16
51583
3,6 mm 0.1417
M4 X 0,35
6,0
66,0
28,0
23,0
36,0
64106
#27 0.1440 3.66
1/4
3
1
53/64 1-7/16
52318
3,7 mm 0.1457
M4.5 X 0,75
6,0
66,0
28,0
23,0
36,0
64107
#26 0.1470 3.73
3/16-24
1/4
3
1
53/64 1-7/16
52319
#25 0.1495 3.80
10-24
1/4
3-1/4 1-1/4 1-5/64 1-7/16
51584
3,8 mm 0.1496
6,0
74,0
36,0
29,0
36,0
64108
#24 0.1520 3.86
10-28
1/4 3-1/4 1-1/4 1-5/64 1-7/16
52321
3,9 mm 0.1535
6,0
74,0
36,0
29,0
36,0
64109
#23 0.1540 3.91
1/4 3-1/4 1-1/4 1-5/64 1-7/16
52322
5/32 0.1562 3.97
1/4
3-1/4 1-1/4 1-5/64 1-7/16
51585
#22 0.1570 3.99
10-30
1/4 3-1/4 1-1/4 1-5/64 1-7/16
52323
4,0 mm 0.1575
M4,5 X 0,5
6,0
74,0
36,0
29,0
36,0
64110
#21 0.1590 4.04
10-32
1/4
3-1/4 1-1/4 1-5/64 1-7/16
51586
#20 0.1610 4.09
13/64-24
1/4
3-1/4 1-1/4 1-5/64 1-7/16
51587
4,1 mm 0.1614
6,0
74,0
36,0
29,0
36,0
64111
4,2 mm 0.1654
M5 / M5 X 0,75 6,0
74,0
36,0
29,0
36,0
64112
#19 0.1660 4.22
1/4 3-1/4 1-1/4 1-5/64 1-7/16
52324
4,3 mm 0.1693
6,0
74,0
36,0
29,0
36,0
64113
#18 0.1695 4.31
1/4 3-1/4 1-1/4 1-5/64 1-7/16
52325
11/64 0.1719 4.37
1/4
3-1/4 1-1/4 1-5/64 1-7/16
51588
#17 0.1730 4.39
1/4 3-1/4 1-1/4 1-5/64 1-7/16
52326
4,4 mm 0.1732
6,0
74,0
36,0
29,0
36,0
64114
4,5 mm 0.1772
M5 X 0,5
6,0
74,0
36,0
29,0
36,0
64115
#15 0.1800 4.57
1/4 3-1/4 1-1/4 1-5/64 1-7/16
52327
4,6 mm 0.1811
12-28
6,0
74,0
36,0
29,0
36,0
64116
#14 0.1820 4.62
1/4 3-1/4 1-1/4 1-5/64 1-7/16
52328
#13 0.1850 4.70
12-32
1/4 3-1/4 1-1/4 1-5/64 1-7/16
52329
4,7 mm 0.1850
6,0
74,0
36,0
29,0
36,0
64117
3/16 0.1875 4.76
1/4
3-1/4 1-3/4 1-37/64 1-7/16
51589
#12 0.1890 4.80
7/32-32
1/4 3-1/4 1-3/4 1-37/64 1-7/16
52330
4,8 mm 0.1890
6,0
82,0
44,0
35,0
36,0
64118
4,9 mm 0.1929
6,0
82,0
44,0
35,0
36,0
64119
#10 0.1935 4.91
14-20
1/4 3-1/4 1-3/4 1-37/64 1-7/16
52331
#9
0.1960 4.98
1/4 3-1/4 1-3/4 1-37/64 1-7/16
52332
5,0 mm 0.1969
M6 X 1
6,0
82,0
44,0
35,0
36,0
64120
#8
0.1990 5.05
1/4 3-1/4 1-3/4 1-37/64 1-7/16
52333
5,1 mm 0.2008
6,0
82,0
44,0
35,0
36,0
64121
#7
0.2010 5.11
1/4-20
1/4
3-1/4 1-3/4 1-37/64 1-7/16
51506
13/64 0.2031 5.16
1/4
3-1/4 1-3/4 1-37/64 1-7/16
51507
#6
0.2040 5.18
1/4
3 1/4 1 3/4 1 37/64 1 7/16
52334
5,2 mm 0.2047
M6 X 0,75
6,0
82,0
44,0
35,0
36,0
64122
#5
0.2055 5.22
1/4
3-1/4 1-3/4 1-37/64 1-7/16
51590
5,25 mm 0.2067
6,0
82,0
44,0
35,0
36,0
64123
5,3 mm 0.2087
6,0
82,0
44,0
35,0
36,0
64124
#4
0.2090 5.31
1/4-24
1/4
3-1/4 1-3/4 1-37/64 1-7/16
51508
continued on next page
FRACTIONAL & METRIC
Hi-PerCarb
CONTINUED
135 5xD
FRACTIONAL & METRIC SERIES
