DRILLS DRILLS 259
www.kyocera-sgstool.com
CUTTING
DIAMETER
D1
DECIMAL
EQUIV.
METRIC
EQUIV.
TAP SIZE
REFERENCE
ONLY
SHANK
DIAMETER
D2
OVERALL
LENGTH
L1
FLUTE
LENGTH
L 2
CLEARED
LENGTH
L 3
SHANK
LENGTH
L4
Ti-NAMITE-A
(AlTiN)
EDP NO.
35/64 0.5469 13.89 5/8-12 5/8 4-7/8 3-1/32 2-19/32 1-49/64 51537
14,0 mm 0.5512 M16 X 2 14,0 124,0 77,0 60,0 45,0 64200
9/16 0.5625 14.29 5/8 5-1/4 3-1/4 2-3/4 1-57/64 51538
14,5 mm 0.5709 M16 X 1,5 16,0 133,0 83,0 63,0 48,0 64201
37/64 0.5781 14.68 5/8-18 5/8 5-1/4 3-1/4 2-3/4 1-57/64 51539
15,0 mm 0.5906 M16 X 1 16,0 133,0 83,0 63,0 48,0 64202
19/32 0.5938 15.08 11/16-11 5/8 5-1/4 3-1/4 2-3/4 1-57/64 51592
39/64 0.6094 15.48 11/16-12 5/8 5-1/4 3-1/4 2-3/4 1-57/64 51593
15,5 mm 0.6102 M18 X 2,5 16,0 133,0 83,0 63,0 48,0 64203
5/8 0.6250 15.88 11/16-16 5/8 5-1/4 3-1/4 2-3/4 1-57/64 51540
16,0 mm 0.6299 16,0 133,0 83,0 63,0 48,0 64204
41/64 0.6406 16.27 11/16-24 3/4 5-5/8 3-5/8 3-3/16 1-57/64 51594
16,5 mm 0.6496 M18 X 1,5 18,0 143,0 93,0 71,0 48,0 64205
21/32 0.6562 16.67 3/4-10 3/4 5-5/8 3-5/8 3-3/16 1-57/64 51541
17,0 mm 0.6693 18,0 143,0 93,0 71,0 48,0 64206
43/64 0.6719 17.07 3/4-12 3/4 5-5/8 3-5/8 3-3/16 1-57/64 51595
11/16 0.6875 17.46 3/4-16 3/4 5-5/8 3-5/8 3-3/16 1-57/64 51542
17,5 mm 0.6890 M20 X 2,5 18,0 143,0 93,0 71,0 48,0 64207
45/64 0.7031 17.86 3/4-20, 1/2-14 NPT 3/4 5-5/8 3-5/8 3-3/16 1-57/64 51543
18,0 mm 0.7087 18,0 143,0 93,0 71,0 48,0 64208
23/32 0.7188 18.26 3/4 6 4 3-3/8 1-31/32 51596
18,5 mm 0.7283 M20 X 1,5 20,0 153,0 101,0 77,0 50,0 64209
47/64 0.7344 18.65 13/16-12 3/4 6 4 3-3/8 1-31/32 51544
19,0 mm 0.7480 20,0 153,0 101,0 77,0 50,0 64210
3/4 0.7500 19.05 13/16-16 3/4 6 4 3-3/8 1-31/32 51545
49/64 0.7656 19.45 7/8-9 7/8 6 4 3-3/8 1-31/32 52355
19,5 mm 0.7677 M22 X 2,5 20,0 153,0 101,0 77,0 50,0 64211
25/32 0.7812 19.84 7/8 6 4 3-3/8 1-31/32 52356
20,0 mm 0.7874 20,0 153,0 101,0 77,0 50,0 64212
51/64 0.7969 20.24 7/8-12 7/8 6 4 3-3/8 1-31/32 52357
20,5 mm 0.8071 22,0 153,0 101,0 77,0 50,0 64533
13/16 0.8125 20.64 7/8-14 7/8 6-1/2 4-1/2 3-7/8 1-31/32 52358
21,0 mm 0.8268 22,0 153,0 101,0 77,0 50,0 64534
22,0 mm 0.8661 22,0 178,0 127,0 108,0 50,0 64535
7/8 0.8750 22.23 15/16-16, 1-8 7/8 6-1/2 4-1/2 3-7/8 1-31/32 52359
59/64 0.9219 23.42 1-12 1 7 5 4-3/8 2-1/8 52360
FRACTIONAL & METRIC
Hi-PerCarb
CONTINUED
135 5xD
FRACTIONAL & METRIC SERIES
