257
CUTTING
DIAMETER
D
1
DECIMAL
EQUIV.
METRIC
EQUIV.
TAP SIZE
REFERENCE
ONLY
SHANK
DIAMETER
D
2
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
CLEARED
LENGTH
L
3
SHANK
LENGTH
L
4
Ti-NAMITE-A
(AlTiN)
EDP NO.
7,25 mm 0.2854
M8 X 0,75
8,0
91,0
53,0
43,0
36,0
64145
7,3 mm 0.2874
8,0
91,0
53,0
43,0
36,0
64146
L
0.2900 7.37
5/16 3-5/8 2-5/64 1-51/64 1-7/16
52345
7,4 mm 0.2913
8,0
91,0
53,0
43,0
36,0
64147
M 0.2950 7.49
5/16 3-5/8 2-5/64 1-51/64 1-7/16
52346
7,5 mm 0.2953
M8 X 0,5
8,0
91,0
53,0
43,0
36,0
64148
19/64 0.2969 7.54
5/16 3-5/8 2-5/64 1-51/64 1-7/16
51516
7,6 mm 0.2992
8,0
91,0
53,0
43,0
36,0
64149
N 0.3020 7.67
5/16 3-5/8 2-5/64 1-51/64 1-7/16
52347
7,7 mm 0.3031
8,0
91,0
53,0
43,0
36,0
64150
7,8 mm 0.3071
M9 X 1,25
8,0
91,0
53,0
43,0
36,0
64151
7,9 mm 0.3110
8,0
91,0
53,0
43,0
36,0
64152
5/16 0.3125 7.94
3/8-16
5/16 3-5/8 2-5/64 1-51/64 1-7/16
51517
8,0 mm 0.3150
M9 X 1
8,0
91,0
53,0
43,0
36,0
64153
O 0.3160 8.03
3/8
4
2-13/32 2-1/8 1-9/16
52348
8,1 mm 0.3189
10,0 103,0 61,0
49,0
40,0
64154
8,2 mm 0.3228
10,0 103,0 61,0
49,0
40,0
64155
P 0.3230 8.20
3/8
4
2-13/32 2-1/8 1-9/16
51518
8,3 mm 0.3268
10,0 103,0 61,0
49,0
40,0
64156
21/64 0.3281 8.33
3/8-20
3/8
4
2-13/32 2-1/8 1-9/16
51519
8,4 mm 0.3307
10,0 103,0 61,0
49,0
40,0
64157
Q 0.3320 8.43
3/8-24
3/8
4
2-13/32 2-1/8 1-9/16
51520
8,5 mm 0.3346
M10 X 1,5
10,0 103,0 61,0
49,0
40,0
64158
8,6 mm 0.3386
10,0 103,0 61,0
49,0
40,0
64159
R 0.3390 8.61
3/8-32
3/8
4
2-13/32 2-1/8 1-9/16
52349
8,7 mm 0.3425
M10 X 1,25 10,0 103,0 61,0
49,0
40,0
64160
11/32 0.3438 8.73
3/8
4
2-13/32 2-1/8 1-9/16
51521
8,8 mm 0.3465
10,0 103,0 61,0
49,0
40,0
64161
S 0.3480 8.84
3/8
4
2-13/32 2-1/8 1-9/16
51522
8,9 mm 0.3504
10,0 103,0 61,0
49,0
40,0
64162
9,0 mm 0.3543
M10 X 1
10,0 103,0 61,0
49,0
40,0
64163
T
0.3580 9.09
3/8
4
2 13/32 2 1/8 1 9/16
52350
9,1 mm 0.3583
10,0 103,0 61,0
49,0
40,0
64164
23/64 0.3594 9.13
3/8
4
2-13/32 2-1/8 1-9/16
51523
9,2 mm 0.3622
M10 X 0,75 10,0 103,0 61,0
49,0
40,0
64165
9,25 mm 0.3642
10,0 103,0 61,0
49,0
40,0
64166
9,3 mm 0.3661
10,0 103,0 61,0
49,0
40,0
64167
U 0.3680 9.35
7/16-14
3/8
4
2-13/32 2-1/8 1-9/16
51524
9,4 mm 0.3701
10,0 103,0 61,0
49,0
40,0
64168
9,5 mm 0.3740
M10 X 0,5
10,0 103,0 61,0
49,0
40,0
64169
3/8 0.3750 9.53
3/8
4
2-13/32 2-1/8 1-9/16
51525
V 0.3770 9.58
1/2
4
2-13/32 2-1/8 1-9/16
52351
9,6 mm 0.3780
10,0 103,0 61,0
49,0
40,0
64170
9,7 mm 0.3819
10,0 103,0 61,0
49,0
40,0
64171
9,8 mm 0.3858
10,0 103,0 61,0
49,0
40,0
64172
W 0.3860 9.80
1/2
4
2-13/32 2-1/8 1-9/16
51526
9,9 mm 0.3898
10,0 103,0 61,0
49,0
40,0
64173
25/64 0.3906 9.92
7/16-20
1/2
4
2-13/32 2-1/8 1-9/16
51527
