Ti-NAMITE-A
(AlTiN)
EDP NO.
CUTTING
DIAMETER
D
1
DECIMAL
EQUIV.
METRIC
EQUIV.
TAP SIZE
REFERENCE
ONLY
SHANK
DIAMETER
D
2
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
CLEARED
LENGTH
L
3
SHANK
LENGTH
L
4
11/32 0.3438 8.73
3/8-32
10,0 103,0 61,0 49,0 40,0
51923
8,8 mm 0.3465
M10 X 1,25 10,0 103,0 61,0 49,0 40,0
63955
8,9 mm 0.3504
10,0 103,0 61,0 49,0 40,0
63956
9,0 mm 0.3543
M10 X 1
10,0 103,0 61,0 49,0 40,0
63957
9,1 mm 0.3583
10,0 103,0 61,0 49,0 40,0
63958
23/64 0.3594 9.13
10,0 103,0 61,0 49,0 40,0
51924
9,2 mm 0.3622
M10 X 0,75 10,0 103,0 61,0 49,0 40,0
63959
9,3 mm 0.3661
10,0 103,0 61,0 49,0 40,0
63960
U 0.3680 9.35
7/16-14
10,0 103,0 61,0 49,0 40,0
51925
9,4 mm 0.3701
10,0 103,0 61,0 49,0 40,0
63961
9,5 mm 0.3740
M11 / M10 X 0,5 10,0 103,0 61,0 49,0 40,0
63962
3/8 0.3750 9.53
10,0 103,0 61,0 49,0 40,0
51926
9,6 mm 0.3780
10,0 103,0 61,0 49,0 40,0
63963
9,7 mm 0.3819
10,0 103,0 61,0 49,0 40,0
63964
9,8 mm 0.3858
10,0 103,0 61,0 49,0 40,0
63965
9,9 mm 0.3898
10,0 103,0 61,0 49,0 40,0
63966
25/64 0.3906 9.92
7/16-20
10,0 103,0 61,0 49,0 40,0
51927
10,0 mm 0.3937
10,0 103,0 61,0 49,0 40,0
63967
10,1 mm 0.3976
12,0 118,0 71,0 56,0 45,0
63968
10,2 mm 0.4016
M12 X 1,75 12,0 118,0 71,0 56,0 45,0
63969
10,3 mm 0.4055
12,0 118,0 71,0 56,0 45,0
63970
13/32 0.4062 10.32
12,0 118,0 71,0 56,0 45,0
51928
10,4 mm 0.4094
12,0 118,0 71,0 56,0 45,0
63971
10,5 mm 0.4134
M12 X 1,5 12,0 118,0 71,0 56,0 45,0
63972
10,6 mm 0.4173
12,0 118,0 71,0 56,0 45,0
63973
10,7 mm 0.4213
12,0 118,0 71,0 56,0 45,0
63974
27/64 0.4219 10.72
1/2-13
12,0 118,0 71,0 56,0 45,0
51929
10,8 mm 0.4252
M12 X 1,25 12,0 118,0 71,0 56,0 45,0
63975
10,9 mm 0.4291
12,0 118,0 71,0 56,0 45,0
63976
11,0 mm 0.4331
M12 X 1
12,0 118,0 71,0 56,0 45,0
63977
11,1 mm 0.4370
12,0 118,0 71,0 56,0 45,0
63978
7/16 0.4375 11.11 1/4-18NPT 12,0 118,0 71,0 56,0 45,0
51930
11,2 mm 0.4409
12,0 118,0 71,0 56,0 45,0
63979
11,3 mm 0.4449
12,0 118,0 71,0 56,0 45,0
63980
continued on next page
140 5xD
FRACTIONAL & METRIC SERIES
• Coolant through design
promotes controlled and
consistent operating
temperatures improving
coolant flow to the
cut while maintaining
strength
• Split point geometry
for improved drill
penetration and accuracy
• Controlled edge honing
for longevity
• Negative corner position
strengthens and protects
• Recommended for
materials ≤ 60 HRc
(≤ 654 Bhn)
2
FRACTIONAL & METRIC
ICe-Carb
®
TOLERANCES
(mm)
≤3
DIAMETER
D
1
=
+0,002/+0,012
D
2
=
h
6
>3–6
DIAMETER
D
1
=
+0,004/+0,016
D
2
=
h
6
>6–10
DIAMETER
D
1
=
+0,006/+0,021
D
2
=
h
6
>10–18
DIAMETER
D
1
=
+0,007/+0,025
D
2
=
h
6
TOLERANCES
(inch)
≤.1181
DIAMETER
D
1
=
+.00008/+.00047
D
2
=
h
6
>.1181–.2362
DIAMETER
D
1
=
+.00016/+.00063
D
2
=
h
6
>.2362–.3937
DIAMETER
D
1
=
+.00024/+.00083
D
2
=
h
6
>.3937–.7087
DIAMETER
D
1
=
+.00028/+.00098
D
2
=
h
6
>.7087–1.1811
DIAMETER
D
1
=
+.00031/+.00114
D
2
=
h
6
For patent
information visit
www.ksptpatents.com
