Ti-NAMITE-A
(AlTiN)
EDP NO.
CUTTING
DIAMETER
D
1
DECIMAL
EQUIV.
METRIC
EQUIV.
TAP SIZE
REFERENCE
ONLY
SHANK
DIAMETER
D
2
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
CLEARED
LENGTH
L
3
SHANK
LENGTH
L
4
11,4 mm 0.4488
12,0 118,0 71,0 56,0 45,0
63981
11,5 mm 0.4528
M12 X 0,5 12,0 118,0 71,0 56,0 45,0
64000
11,6 mm 0.4567
12,0 118,0 71,0 56,0 45,0
63982
11,7 mm 0.4606
12,0 118,0 71,0 56,0 45,0
63983
11,8 mm 0.4646
12,0 118,0 71,0 56,0 45,0
63984
11,9 mm 0.4685
12,0 118,0 71,0 56,0 45,0
63985
15/32 0.4688 11.91
1/2-28
12,0 118,0 71,0 56,0 45,0
51932
12,0 mm 0.4724
M14 X 2
12,0 118,0 71,0 56,0 45,0
63986
31/64 0.4844 12.30 9/16-12
14,0 124,0 77,0 60,0 45,0
51933
12,5 mm 0.4921
M14 X 1,5 14,0 124,0 77,0 60,0 45,0
63987
1/2 0.5000 12.70
14,0 124,0 77,0 60,0 45,0
51934
12,8 mm 0.5039
M14 X 1,25 14,0 124,0 77,0 60,0 45,0
63988
13,0 mm 0.5118
M14 X 1
14,0 124,0 77,0 60,0 45,0
63989
33/64 0.5156 13.10 9/16-18
14,0 124,0 77,0 60,0 45,0
51935
13,5 mm 0.5315
5/8-11
14,0 124,0 77,0 60,0 45,0
64001
13,8 mm 0.5433
14,0 124,0 77,0 60,0 45,0
63990
14,0 mm 0.5512
M16 X 2
14,0 124,0 77,0 60,0 45,0
63991
9/16 0.5625 14.29
16,0 133,0 83,0 63,0 48,0
51937
14,5 mm 0.5709
M16 X 1,5 16,0 133,0 83,0 63,0 48,0
63992
37/64 0.5781 14.68
5/8-18
16,0 133,0 83,0 63,0 48,0
51938
14,8 mm 0.5827
16,0 133,0 83,0 63,0 48,0
63993
15,0 mm 0.5906
M16 X 1
16,0 133,0 83,0 63,0 48,0
63994
15,5 mm 0.6102
M18 X 2,5 16,0 133,0 83,0 63,0 48,0
63995
15,8 mm 0.6220
16,0 133,0 83,0 63,0 48,0
63996
5/8 0.6250 15.88 11/16-16
16,0 133,0 83,0 63,0 48,0
51939
16,0 mm 0.6299
16,0 133,0 83,0 63,0 48,0
63997
21/32 0.6562 16.67
3/4-10
18,0 143,0 93,0 71,0 48,0
51940
11/16 0.6875 17.46
3/4-16
18,0 143,0 93,0 71,0 48,0
51941
3/4 0.7500 19.05 13/16-16
20,0 153,0 101,0 77,0 50,0
51942
140 5xD
