281 / 396
DRILLS
DRILLS
281
www.kyocera-sgstool.com
®
mm
Ti-NAMITE-A
(AlTiN)
EDP NO.
CUTTING
DIAMETER
D
1
DECIMAL
EQUIV.
METRIC
EQUIV.
TAP SIZE
REFERENCE
ONLY
SHANK
DIAMETER
D
2
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
CLEARED
LENGTH
L
3
SHANK
LENGTH
L
4
7/32 0.2188 5.56
1/4-32
6,0 82,0 44,0 35,0 36,0
51912
5,6 mm 0.2205
6,0 82,0 44,0 35,0 36,0
63924
5,7 mm 0.2244
6,0 82,0 44,0 35,0 36,0
63925
5,8 mm 0.2283
6,0 82,0 44,0 35,0 36,0
63926
5,9 mm 0.2323
6,0 82,0 44,0 35,0 36,0
63927
15/64 0.2344 5.95
6,0 82,0 44,0 35,0 36,0
51913
6,0 mm 0.2362
M7 X 1
6,0 82,0 44,0 35,0 36,0
63928
6,1 mm 0.2402
8,0 91,0 53,0 43,0 36,0
63929
6,2 mm 0.2441
M7 X 0,75 8,0 91,0 53,0 43,0 36,0
63930
6,3 mm 0.2480
8,0 91,0 53,0 43,0 36,0
63931
1/4 0.2500 6.35
8,0 91,0 53,0 43,0 36,0
51914
6,4 mm 0.2520
8,0 91,0 53,0 43,0 36,0
63932
6,5 mm 0.2559
8,0 91,0 53,0 43,0 36,0
63933
F
0.2570 6.53
5/16-18
8,0 91,0 53,0 43,0 36,0
51915
6,6 mm 0.2598
8,0 91,0 53,0 43,0 36,0
63934
6,7 mm 0.2638
8,0 91,0 53,0 43,0 36,0
63935
17/64 0.2656 6.75
5/16-20
8,0 91,0 53,0 43,0 36,0
51916
6,8 mm 0.2677
M8 X 1,25 8,0 91,0 53,0 43,0 36,0
63936
6,9 mm 0.2717
5/16-24
8,0 91,0 53,0 43,0 36,0
63999
7,0 mm 0.2756
M8 X 1
8,0 91,0 53,0 43,0 36,0
63937
7,1 mm 0.2795
8,0 91,0 53,0 43,0 36,0
63938
9/32 0.2812 7.14
5/16-32
8,0 91,0 53,0 43,0 36,0
51918
7,2 mm 0.2835
M8 X 0,75 8,0 91,0 53,0 43,0 36,0
63939
7,3 mm 0.2874
8,0 91,0 53,0 43,0 36,0
63940
7,4 mm 0.2913
8,0 91,0 53,0 43,0 36,0
63941
7,5 mm 0.2953
M8 X 0,5
8,0 91,0 53,0 43,0 36,0
63942
19/64 0.2969 7.54
8,0 91,0 53,0 43,0 36,0
51919
7,6 mm 0.2992
8,0 91,0 53,0 43,0 36,0
63943
7,7 mm 0.3031
8,0 91,0 53,0 43,0 36,0
63944
7,8 mm 0.3071
M9 X 1,25 8,0 91,0 53,0 43,0 36,0
63945
7,9 mm 0.3110
8,0 91,0 53,0 43,0 36,0
63946
5/16 0.3125 7.94
3/8-16
8,0 91,0 53,0 43,0 36,0
51920
8,0 mm 0.3150
M9 X 1
8,0 91,0 53,0 43,0 36,0
63947
8,1 mm 0.3189
10,0 103,0 61,0 49,0 40,0
63948
8,2 mm 0.3228
10,0 103,0 61,0 49,0 40,0
63949
8,3 mm 0.3268
10,0 103,0 61,0 49,0 40,0
63950
21/64 0.3281 8.33
3/8-20
10,0 103,0 61,0 49,0 40,0
51921
8,4 mm 0.3307
10,0 103,0 61,0 49,0 40,0
63951
Q 0.3320 8.43
3/8-24
10,0 103,0 61,0 49,0 40,0
51922
8,5 mm 0.3346
M10 X 1,5 10,0 103,0 61,0 49,0 40,0
63952
8,6 mm 0.3386
10,0 103,0 61,0 49,0 40,0
63953
8,7 mm 0.3425
10,0 103,0 61,0 49,0 40,0
63954
continued on next page
FRACTIONAL & METRIC
ICe-Carb
®
CONTINUED
140 5xD
FRACTIONAL & METRIC SERIES
