DRILLS
DRILLS
277
www.kyocera-sgstool.com
CUTTING
DIA.
D
1
DECIMAL
EQUIV.
METRIC
EQUIV.
TAP SIZE
REFERENCE
ONLY
SHANK
DIA.
D
2
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
CLEARED
LENGTH
L
3
SHANK
LENGTH
L
4
Ti-NAMITE-M
(TM)
EDP NO.
31/64 0.4844 12.30
9/16-12
14,0 124,0 77,0 60,0 45,0
55187
12,5 mm 0.4921
M14 X 1,5
14,0 124,0 77,0 60,0 45,0
65251
1/2
0.5000 12.70
14,0 124,0 77,0 60,0 45,0
55188
12,8 mm 0.5039
M14 X 1,25
14,0 124,0 77,0 60,0 45,0
65252
13,0 mm 0.5118
M14 X 1
14,0 124,0 77,0 60,0 45,0
65253
33/64 0.5156 13.10
9/16-18
14,0 124,0 77,0 60,0 45,0
55189
13,5 mm 0.5315
5/8-11
14,0 124,0 77,0 60,0 45,0
65254
13,8 mm 0.5433
14,0 124,0 77,0 60,0 45,0
65255
14,0 mm 0.5512
M16 X 2
14,0 124,0 77,0 60,0 45,0
65256
9/16 0.5625 14.29
16,0 133,0 83,0 63,0 48,0
55190
14,5 mm 0.5709
M16 X 1,5
16,0 133,0 83,0 63,0 48,0
65257
37/64 0.5781 14.68
5/8-18
16,0 133,0 83,0 63,0 48,0
55191
14,8 mm 0.5827
16,0 133,0 83,0 63,0 48,0
65258
15,0 mm 0.5906
M16 X 1
16,0 133,0 83,0 63,0 48,0
65259
15,5 mm 0.6102
M18 X 2,5
16,0 133,0 83,0 63,0 48,0
65260
15,8 mm 0.6220
16,0 133,0 83,0 63,0 48,0
65261
5/8
0.6250 15.88
11/16-16
16,0 133,0 83,0 63,0 48,0
55192
16,0 mm 0.6299
16,0 133,0 83,0 63,0 48,0
65262
21/32 0.6562 16.67
3/4-10
18,0 143,0 93,0 71,0 48,0
55193
11/16 0.6875 17.46
3/4-16
18,0 143,0 93,0 71,0 48,0
55194
3/4
0.7500 19.05
13/16-16
20,0 153,0 101,0 77,0 50,0
55195
FRACTIONAL & METRIC
Hi-PerCarb
CONTINUED
141K 5xD
FRACTIONAL & METRIC SERIES
