280 / 396
DRILLS
DRILLS
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
NON-FERROUS
HARDENEDSTEELS
280
www.kyocera-sgstool.com
®
mm
Ti-NAMITE-A
(AlTiN)
EDP NO.
CUTTING
DIAMETER
D
1
DECIMAL
EQUIV.
METRIC
EQUIV.
TAP SIZE
REFERENCE
ONLY
SHANK
DIAMETER
D
2
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
CLEARED
LENGTH
L
3
SHANK
LENGTH
L
4
3,0 mm 0.1181
6,0 66,0 28,0 23,0 36,0
63901
3,1 mm 0.1220
6,0 66,0 28,0 23,0 36,0
63902
1/8 0.1250 3.18
6,0 66,0 28,0 23,0 36,0
51901
3,2 mm 0.1260
M3,5 X 0,35 6,0 66,0 28,0 23,0 36,0
63903
3,3 mm 0.1299
M4 X 0,7
6,0 66,0 28,0 23,0 36,0
63904
3,4 mm 0.1339
6,0 66,0 28,0 23,0 36,0
63905
#
29 0.1360 3.45 8-32,8-36
6,0 66,0 28,0 23,0 36,0
51902
3,5 mm 0.1378
M4 X 0,5
6,0 66,0 28,0 23,0 36,0
63906
9/64 0.1406 3.57
6,0 66,0 28,0 23,0 36,0
51903
3,6 mm 0.1417
M4 X 0,35 6,0 66,0 28,0 23,0 36,0
63907
3,7 mm 0.1457
M4,5 X 0,75 6,0 66,0 28,0 23,0 36,0
63908
3,8 mm 0.1496
10-24
6,0 74,0 36,0 29,0 36,0
51904
3,9 mm 0.1535
6,0 74,0 36,0 29,0 36,0
63909
5/32 0.1562 3.97
6,0 74,0 36,0 29,0 36,0
51905
4,0 mm 0.1575
M4,5 X 0,5 6,0 74,0 36,0 29,0 36,0
63910
#
21 0.1590 4.04
10-32
6,0 74,0 36,0 29,0 36,0
51906
4,1 mm 0.1614
6,0 74,0 36,0 29,0 36,0
63911
4,2 mm 0.1654
M5 / M5 x 0,75 6,0 74,0 36,0 29,0 36,0
63912
4,3 mm 0.1693
6,0 74,0 36,0 29,0 36,0
63913
11/64 0.1719 4.37
6,0 74,0 36,0 29,0 36,0
51907
4,4 mm 0.1732
12-24
6,0 74,0 36,0 29,0 36,0
63914
4,5 mm 0.1772
M5 X 0,5
6,0 74,0 36,0 29,0 36,0
63915
4,6 mm 0.1811
12-28
6,0 74,0 36,0 29,0 36,0
63916
4,7 mm 0.1850
12-32
6,0 74,0 36,0 29,0 36,0
63917
3/16 0.1875 4.76
6,0 82,0 44,0 35,0 36,0
51908
4,8 mm 0.1890
7/32-32
6,0 82,0 44,0 35,0 36,0
63918
4,9 mm 0.1929
6,0 82,0 44,0 35,0 36,0
63919
5,0 mm 0.1969
M6 X 1
6,0 82,0 44,0 35,0 36,0
63920
5,1 mm 0.2008
1/4-20
6,0 82,0 44,0 35,0 36,0
63900
13/64 0.2031 5.16
6,0 82,0 44,0 35,0 36,0
51910
5,2 mm 0.2047
M6 X 0,75 6,0 82,0 44,0 35,0 36,0
63921
5,3 mm 0.2087
6,0 82,0 44,0 35,0 36,0
63922
5,4 mm 0.2126
6,0 82,0 44,0 35,0 36,0
63998
5,5 mm 0.2165
M6 X 0,5
6,0 82,0 44,0 35,0 36,0
63923
continued on next page
FRACTIONAL & METRIC
ICe-Carb
®
140 5xD
FRACTIONAL & METRIC SERIES
2
• Coolant through design
promotes controlled and
consistent operating
temperatures improving
coolant flow to the
cut while maintaining
strength
• Split point geometry
for improved drill
penetration and accuracy
• Controlled edge honing
for longevity
• Negative corner position
strengthens and protects
• Recommended for
materials ≤ 60 HRc
(≤ 654 Bhn)
TOLERANCES
(mm)
≤3
DIAMETER
D
1
=
+0,002/+0,012
D
2
=
h
6
>3–6
DIAMETER
D
1
=
+0,004/+0,016
D
2
=
h
6
>6–10
DIAMETER
D
1
=
+0,006/+0,021
D
2
=
h
6
>10–18
DIAMETER
D
1
=
+0,007/+0,025
D
2
=
h
6
TOLERANCES
(inch)
≤.1181
DIAMETER
D
1
=
+.00008/+.00047
D
2
=
h
6
>.1181–.2362
DIAMETER
D
1
=
+.00016/+.00063
D
2
=
h
6
>.2362–.3937
DIAMETER
D
1
=
+.00024/+.00083
D
2
=
h
6
>.3937–.7087
DIAMETER
D
1
=
+.00028/+.00098
D
2
=
h
6
>.7087–1.1811
DIAMETER
D
1
=
+.00031/+.00114
D
2
=
h
6
For patent
information visit
www.ksptpatents.com
