END MILLS
END MILLS
55M
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
Ti-NAMITE-A
(AlTiN)
Ti-NAMITE-A
(AlTiN)
W/FLAT
6,0
12,0
50,0
6,0
42606
–
6,0
19,0
63,0
6,0
42607
–
6,0
25,0
75,0
6,0
42608
–
8,0
12,0
50,0
8,0
42609
–
8,0
20,0
63,0
8,0
42610
–
8,0
25,0
75,0
8,0
42611
–
10,0
16,0
50,0
10,0
42612
–
10,0
22,0
75,0
10,0
42622
42613
10,0
38,0
100,0
10,0
42614
–
12,0
19,0
63,0
12,0
42615
–
12,0
25,0
75,0
12,0
42616
42623
12,0
50,0
100,0
12,0
42617
–
16,0
32,0
89,0
16,0
42618
42624
16,0
50,0
100,0
16,0
42626
–
16,0
75,0
150,0
16,0
42619
–
20,0
38,0
100,0
20,0
42620
42625
20,0
50,0
100,0
20,0
42627
–
20,0
75,0
150,0
20,0
42621
–
METRIC
V-Carb
• Unequal indexing, high
helix and an ideal rake
and relief combination
for unmatched finishing
capability
• The choice when peak
finish quality is the
requirement
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
≠
POS
5
TOLERANCES
(mm)
D
1
=
+0,000/–0,050
D
2
=
h
6
For patent
information visit
www.ksptpatents.com
