END MILLS
END MILLS
55MCR
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
CORNER
RADIUS
R
Ti-NAMITE-A
(AlTiN)
6,0
12,0
50,0
6,0
0,5
42660
6,0
19,0
63,0
6,0
0,25
42661
6,0
19,0
63,0
6,0
0,5
42662
6,0
19,0
63,0
6,0
1,0
42663
6,0
19,0
63,0
6,0
1,5
42664
6,0
25,0
75,0
6,0
0,5
42665
8,0
12,0
50,0
8,0
0,5
42666
8,0
20,0
63,0
8,0
0,5
42667
8,0
20,0
63,0
8,0
1,0
42668
8,0
20,0
63,0
8,0
1,5
42669
8,0
20,0
63,0
8,0
2,0
42670
8,0
25,0
75,0
8,0
0,5
42671
10,0
16,0
50,0
10,0
0,5
42672
10,0
22,0
75,0
10,0
0,5
42673
10,0
22,0
75,0
10,0
1,0
42674
10,0
22,0
75,0
10,0
1,5
42675
10,0
22,0
75,0
10,0
2,0
42676
10,0
22,0
75,0
10,0
2,5
42677
10,0
38,0
100,0
10,0
0,5
42678
12,0
19,0
63,0
12,0
0,5
42679
12,0
25,0
75,0
12,0
0,5
42680
12,0
25,0
75,0
12,0
1,0
42681
12,0
25,0
75,0
12,0
1,5
42682
12,0
25,0
75,0
12,0
2,0
42683
12,0
25,0
75,0
12,0
2,5
42684
12,0
25,0
75,0
12,0
3,0
42685
12,0
50,0
100,0
12,0
0,5
42686
12,0
50,0
100,0
12,0
3,0
42630
12,0
50,0
100,0
12,0
4,0
42631
16,0
32,0
89,0
16,0
1,0
42687
16,0
32,0
89,0
16,0
1,5
42688
16,0
32,0
89,0
16,0
2,0
42689
METRIC
V-Carb
• Unequal indexing, high
helix and an ideal rake
and relief combination
for unmatched finishing
capability
• The choice when peak
finish quality is the
requirement
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
≠
POS
5
TOLERANCES
(mm)
D
1
=
+0,000/–0,050
D
2
=
h
6
R =
+0,000/–0,050
continued on next page
For patent
information visit
www.ksptpatents.com
