STEELS

STAINLESSSTEELS

CAST IRON

HIGHTEMPALLOYS

TITANIUM

HARDENEDSTEELS

64

www.kyocera-sgstool.com

END MILLS

END MILLS

55CR

FRACTIONAL SERIES

inch

EDP NO.

CUTTING

DIAMETER

D

1

LENGTH

OF CUT

L

2

OVERALL

LENGTH

L

1

SHANK

DIAMETER

D

2

CORNER

RADIUS

R

Ti-NAMITE-A

(AlTiN)

Ti-NAMITE-A

(AlTiN)

W/FLAT

1/8

1/4

1-1/2

1/8

.010

32606

–

1/8

1/2

1-1/2

1/8

.010

32607

–

5/32

5/16

2

3/16

.010

32608

–

5/32

9/16

2

3/16

.010

32609

–

3/16

5/16

2

3/16

.010

32610

–

3/16

5/8

2

3/16

.010

32611

–

7/32

3/8

2

1/4

.015

32612

–

7/32

3/4

2-1/2

1/4

.015

32613

–

1/4

3/8

2

1/4

.015

32614

–

1/4

3/4

2-1/2

1/4

.015

32615

–

1/4

1-1/4

4

1/4

.015

32616

–

5/16

7/16

2

5/16

.015

32619

–

5/16

13/16

2-1/2

5/16

.015

32620

–

5/16

1-1/4

4

5/16

.015

32621

–

3/8

1/2

2

3/8

.015

32625

32591

3/8

1/2

2

3/8

.030

32592

32593

3/8

1

2-1/2

3/8

.015

32626

32628

3/8

1

2-1/2

3/8

.030

32573

32574

3/8

1-1/2

4

3/8

.015

32627

–

3/8

1-1/2

4

3/8

.030

32569

–

7/16

1

2-3/4

7/16

.015

32632

–

7/16

2

4

7/16

.015

32633

–

1/2

5/8

2-1/2

1/2

.030

32594

32595

1/2

5/8

2-1/2

1/2

.060

32596

32597

1/2

1-1/4

3

1/2

.030

32575

32576

1/2

1-1/4

3

1/2

.060

32577

32578

1/2

2

4

1/2

.030

32685

–

1/2

2

4

1/2

.060

32686

–

5/8

3/4

3

5/8

.030

32598

32599

5/8

3/4

3

5/8

.060

32600

32601

5/8

1-5/8

3-1/2

5/8

.030

32579

32580

5/8

1-5/8

3-1/2

5/8

.060

32581

32582

5/8

2-1/2

5

5/8

.030

32570

–

5/8

2-1/2

5

5/8

.060

32687

–

3/4

1

3

3/4

.030

32602

32603

3/4

1

3

3/4

.060

32604

32605

3/4

1-5/8

4

3/4

.030

32583

32584

3/4

1-5/8

4

3/4

.060

32585

32586

3/4

3-1/4

6

3/4

.030

32571

–

3/4

3-1/4

6

3/4

.060

32688

–

1

1-1/2

4

1

.030

32587

32588

1

1-1/2

4

1

.060

32589

32590

1

2-5/8

6

1

.030

32572

–

1

2-5/8

6

1

.060

32689

–

FRACTIONAL

V-Carb

• Unequal indexing, high

helix and an ideal rake

and relief combination

for unmatched finishing

capability

• The choice when peak

finish quality is the

requirement

• Enhanced corner

geometry with tight

tolerance corner radii

• Recommended for

materials ≤ 45 HRc

(≤ 420 Bhn)

≠

POS

5

TOLERANCES

(inch)

D

1

=

+0.0000/–0.0020

D

2

=

h

6

R =

+0.0000/–0.0020

For patent

information visit

www.ksptpatents.com
