65 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
65
www.kyocera-sgstool.com
END MILLS
END MILLS
FRACTIONAL
V-Carb
55B
FRACTIONAL SERIES
inch
EDP NO.
CUTTING DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
Ti-NAMITE-A
(AlTiN)
1/4
3/4
2-1/2
1/4
32500
5/16
13/16
2-1/2
5/16
32501
3/8
1
2-1/2
3/8
32502
1/2
1-1/4
3
1/2
32503
5/8
1-5/8
3-1/2
5/8
32504
3/4
1-5/8
4
3/4
32505
1
1-1/2
4
1
32506
• Unequal indexing, high
helix and an ideal rake
and relief combination
for unmatched finishing
capability
• The choice when peak
finish quality is the
requirement
• Ball nose design ideal
for finishing operations
in complex workpieces
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
≠
POS
5
For patent
information visit
www.ksptpatents.com
TOLERANCES
(inch)
D
1
=
+0.0000/–0.0020
D
2
=
h
6
BALL RADIUS
+0.0005/–0.0010
2
D
1
D
≠
45°
L
1
L
2
