END MILLS
END MILLS
www.kyocera-sgstool.com
55MB
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
Ti-NAMITE-A
(AlTiN)
6,0
13,0
57,0
6,0
42750
8,0
19,0
63,0
8,0
42751
10,0
22,0
72,0
10,0
42752
12,0
26,0
83,0
12,0
42753
16,0
32,0
92,0
16,0
42754
20,0
38,0
104,0
20,0
42755
≠
POS
5
• Unequal indexing, high
helix and an ideal rake
and relief combination
for unmatched finishing
capability
• The choice when peak
finish quality is the
requirement
• Ball nose design ideal
for finishing operations
in complex workpieces
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
METRIC
V-Carb
TOLERANCES
(mm)
D
1
=
+0,000/–0,050
D
2
=
h
6
BALL RADIUS
+0,000/–0,025
For patent
information visit
www.ksptpatents.com
2
D
1
D
≠
45°
L
1
L
2
