75 / 396
STEELS
STAINLESSSTEELS
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
75
www.kyocera-sgstool.com
END MILLS
END MILLS
51
FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
TI-NAMITE-X
(TX)
1/4
3/4
2-1/2
1/4
35100
3/8
1
2-1/2
3/8
35101
1/2
1-1/4
3
1/2
35102
5/8
1-5/8
3-1/2
5/8
35103
3/4
1-5/8
4
3/4
35104
1
2-5/8
6
1
35105
≠
POS
6
TOLERANCES
(inch)
D
1
=
+0.0000/–0.0020
D
2
=
h6
• Engineered for High
Speed Milling using
Trochoidal and Peel
Milling techniques
• Eccentric relief provides
superior strength and
smoother surface finish
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
FRACTIONAL
T-Carb
®
®
2
D
L
1
L
2
1
D
≠
41°
STEELS
STAINLESSSTEELS
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
51CR
FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
CORNER
RADIUS
R
TI-NAMITE-X
(TX)
1/4
3/4
2-1/2
1/4
.015
35112
1/4
3/4
2-1/2
1/4
.030
35150
3/8
1
2-1/2
3/8
.015
35113
3/8
1
2-1/2
3/8
.030
35114
1/2
1-1/4
3
1/2
.015
35151
1/2
1-1/4
3
1/2
.030
35115
1/2
1-1/4
3
1/2
.060
35152
1/2
1-1/4
3
1/2
.090
35116
1/2
1-1/4
3
1/2
.120
35117
5/8
1-5/8
3-1/2
5/8
.015
35153
5/8
1-5/8
3-1/2
5/8
.030
35118
5/8
1-5/8
3-1/2
5/8
.060
35154
5/8
1-5/8
3-1/2
5/8
.090
35119
5/8
1-5/8
3-1/2
5/8
.120
35120
5/8
1-5/8
3-1/2
5/8
.190
35155
3/4
1-5/8
4
3/4
.030
35121
3/4
1-5/8
4
3/4
.060
35156
3/4
1-5/8
4
3/4
.090
35122
3/4
1-5/8
4
3/4
.120
35123
3/4
1-5/8
4
3/4
.190
35157
3/4
1-5/8
4
3/4
.250
35158
1
2-5/8
6
1
.030
35124
1
2-5/8
6
1
.060
35159
1
2-5/8
6
1
.090
35125
1
2-5/8
6
1
.120
35126
1
2-5/8
6
1
.190
35160
1
2-5/8
6
1
.250
35161
TOLERANCES
(inch)
D
1
=
+0.0000/–0.0020
D
2
=
h6
R =
+0,0000/–0.0020
• Engineered for High
Speed Milling using
Trochoidal and Peel
Milling techniques
• Eccentric relief provides
superior strength and
smoother surface finish
• Enhanced corner
geometry with tight
tolerance corner radii
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
For patent
information visit
www.ksptpatents.com
For patent
information visit
www.ksptpatents.com
2
D
L
1
L
2
1
D
≠
R
41°
