END MILLS
END MILLS
51L
FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
REACH
L
3
TI-NAMITE-X
(TX)
1/4
3/8
4
1/4
1-1/8
35106
3/8
1/2
4
3/8
2-1/8
35107
1/2
5/8
4
1/2
2-1/4
35108
5/8
3/4
5
5/8
2-1/2
35109
3/4
1
6
3/4
3-3/8
35110
1
1-1/4
6
1
3-3/8
35111
≠
POS
6
TOLERANCES
(inch)
D
1
=
+0.0000/–0.0020
D
2
=
h6
• Engineered for High
Speed Milling using
Trochoidal and Peel
Milling techniques
• Eccentric relief provides
superior strength and
smoother surface finish
• Necked design with
blended diameter
transitions provide
clearance to reach
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
FRACTIONAL
T-Carb
®
®
2
D
L
1
L
2
L
3
1
D
≠
41°
For patent
information visit
www.ksptpatents.com
