END MILLS
END MILLS
43MAPF
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
REACH
L
3
CORNER
RADIUS
R
Ti-NAMITE-B
(TiB
2
)
6,0
24,0
58,0
6,0
30,0
–
44627
8,0
32,0
64,0
8,0
40,0
–
44628
10,0
40,0
80,0
10,0
50,0
–
44629
12,0
30,0
83,0
12,0
40,0
–
44630
12,0
30,0
83,0
12,0
40,0
2,0
44745
12,0
30,0
83,0
12,0
40,0
3,0
44746
12,0
30,0
83,0
12,0
40,0
4,0
44747
12,0
30,0
83,0
12,0
50,0
0,5
44641
12,0
30,0
83,0
12,0
50,0
5,0
44642
12,0
48,0
100,0
12,0
62,0
–
44631
12,0
48,0
100,0
12,0
62,0
2,0
44748
12,0
48,0
100,0
12,0
62,0
3,0
44749
12,0
48,0
100,0
12,0
62,0
4,0
44750
16,0
42,0
93,0
16,0
51,0
5,0
44643
16,0
40,0
92,0
16,0
51,0
–
44634
16,0
40,0
92,0
16,0
51,0
2,0
44751
16,0
40,0
92,0
16,0
51,0
3,0
44752
16,0
40,0
92,0
16,0
51,0
4,0
44753
16,0
64,0
125,0
16,0
82,0
–
44635
16,0
64,0
125,0
16,0
82,0
2,0
44754
16,0
64,0
125,0
16,0
82,0
3,0
44755
16,0
64,0
125,0
16,0
82,0
4,0
44756
20,0
50,0
108,0
20,0
63,0
–
44636
20,0
50,0
108,0
20,0
63,0
3,0
44757
20,0
50,0
108,0
20,0
63,0
4,0
44758
20,0
50,0
108,0
20,0
63,0
5,0
44759
20,0
80,0
150,0
20,0
102,0
–
44637
20,0
80,0
150,0
20,0
102,0
3,0
44760
20,0
80,0
150,0
20,0
102,0
4,0
44761
20,0
80,0
150,0
20,0
102,0
5,0
44762
25,0
63,0
130,0
25,0
79,0
–
44638
25,0
63,0
130,0
25,0
79,0
3,0
44763
25,0
63,0
130,0
25,0
79,0
4,0
44764
25,0
63,0
130,0
25,0
79,0
5,0
44765
25,0
100,0
175,0
25,0
120,0
–
44639
25,0
100,0
175,0
25,0
120,0
3,0
44766
25,0
100,0
175,0
25,0
120,0
4,0
44767
25,0
100,0
175,0
25,0
120,0
5,0
44768
Available on request: • JetStream Technology
METRIC
S-Carb APF
®
®
≠
POS
4
TOLERANCES
(mm)
6–25
DIAMETER
D
1
=
+0,010/–0,050
D
2
=
h
6
R =
+0,000/–0,030
• Ultra high-productivity
finisher for Aluminum
alloys, specifically for
aircraft components
• Two levels of chatter
suppression: variable
helix and indexing
• Designed for single axial
pass semi-finishing and
finishing
• Polished flutes maximize
chip evacuation and
provides enhanced finish
• Recommended for
materials ≤ 150 Bhn
(≤ 7 HRc)
For patent
information visit
www.ksptpatents.com
2
D
1
D
R
L
1
L
2
L
3
38°
41°
