FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED
Ti-NAMITE-B
(TiB
2
)
1/8
3/8
1-1/2
1/8
34701
34728
3/16
5/16
2-1/2
3/16
34822
34857
3/16
9/16
2
3/16
34702
34729
3/16
3/4
2-1/2
3/16
34823
34858
1/4
3/8
2
1/4
34703
34730
1/4
1/2
2-1/2
1/4
34824
34859
1/4
3/4
2-1/2
1/4
34704
34731
1/4
1
3
1/4
34825
34860
1/4
1-1/4
3-1/2
1/4
34705
34732
1/4
1-3/4
4
1/4
34826
34861
5/16
7/16
2
5/16
34706
34733
5/16
5/8
2-1/2
5/16
34707
34734
5/16
1-1/4
4
5/16
34708
34735
3/8
1/2
2
3/8
34709
34736
3/8
1
2-1/2
3/8
34710
34737
3/8
1-1/4
3-1/2
3/8
34827
34862
3/8
1-1/2
3-1/2
3/8
34711
34738
3/8
2
4
3/8
34828
34863
1/2
5/8
2-1/2
1/2
34712
34739
1/2
1
3
1/2
34830
34865
1/2
1-1/4
3-1/4
1/2
34713
34740
1/2
1-5/8
4
1/2
34831
34866
1/2
2-1/2
5
1/2
34832
34867
1/2
2
4
1/2
34714
34741
1/2
3-1/8
6
1/2
34715
34742
5/8
3/4
3
5/8
34716
34743
5/8
1-5/8
3-3/4
5/8
34717
34744
5/8
2-1/8
4
5/8
34833
34868
5/8
2-1/2
5
5/8
34718
34745
5/8
3-1/4
6
5/8
34834
34869
5/8
3-3/4
6
5/8
34719
34746
3/4
1
3
3/4
34720
34747
3/4
1-5/8
4
3/4
34721
34748
3/4
2-1/4
5
3/4
34722
34749
3/4
3-1/4
6
3/4
34723
34750
1
1-1/4
4
1
34724
34751
1
2
4-1/2
1
34725
34752
1
2-5/8
6
1
34726
34753
1
3-1/4
6
1
34727
34754
1
4-1/8
7
1
34835
34870
FRACTIONAL
S-Carb
®
• Circular land allows
for increased control
at various speed and
feed rates and reduces
chatter
• Symmetrical end gashing
for excellent balance
at high speeds and
aggressive plunging
capability
• Open fluting for deep
slotting and profiling
• Recommended for
materials ≤ 150 Bhn
(≤ 7 HRc)
POS
3
TOLERANCES
(inch)
1/8–3/16
DIAMETER
D
1
=
+0.0000/–0.00032
D
2
=
h
6
1/4–3/8
DIAMETER
D
1
=
+0.0000/–0.00035
D
2
=
h
6
1/2–5/8
DIAMETER
D
1
=
+0.0000/–0.00043
D
2
=
h
6
3/4–1
DIAMETER
D
1
=
+0.0000/–0.00051
D
2
=
h
6
®
For patent
information visit
www.ksptpatents.com
