END MILLS
END MILLS
METRIC
S-Carb APF
®
Series
43MAPF
Metric
Hardness
Ap
Ae
Ae
Vc
(m/min)
Diameter (D
1
)
(mm)
Ae x D
1
Ap x D
1
6 8 10 12 16 20 25
N
ALUMINUM ALLOYS
2024, 5052, 5086, 6061,
6063, 7075
≤ 150 Bhn
or
≤ 7 HRc
Profile
≤ 0.1
≤ 2.5
800
RPM 42440 31830 25464 21220 15915 12732 10186
(640-960)
Fz
0.050 0.055 0.060 0.070 0.100 0.140 0.170
Feed (mm/min) 8488 7003 6111 5942 6366 7130 6926
Profile
≤ 0.1
≤ 4
800
RPM 42440 31830 25464 21220 15915 12732 10186
(640-960)
Fz
0.040 0.045 0.050 0.050 0.070 0.100 0.120
Feed (mm/min) 6790 5729 5093 4244 4456 5093 4889
ALUMINUM ALLOYS
(LITHIUM)*
2090, 2091, 2099, 2195,
2199, 2297, 8090
≤ 150 Bhn
or
≤ 7 HRc
Profile
≤ 0.1
≤ 2.5
600
RPM 31830 23873 19098 15915 11936 9549 7639
(480-720)
Fz
0.050 0.055 0.060 0.070 0.100 0.140 0.170
Feed (mm/min) 6366 5252 4584 4456 4774 5347 5195
Profile
≤ 0.1
≤ 4
600
RPM 31830 23873 19098 15915 11936 9549 7639
(480-720)
Fz
0.040 0.045 0.050 0.050 0.070 0.100 0.120
Feed (mm/min) 5093 4297 3820 3183 3342 3820 3667
Bhn (Brinell) HRc (Rockwell C)
surface speed is dependent on machine spindle and fixturing
balancing is recommended at ultra high surface speeds
*tool life may be reduced when machining Lithium Alloys
rpm = (Vc x 1000) / (D
1
x 3.14)
mm/min = Fz x 4 x rpm
maximum recommended depths shown
reduce speed and feed for materials harder than listed
finish cuts typically require reduced feed and cutting depths of 0.02 X D
1
maximum
ramp angle = 6˚ (feed rate = 50%)
plunging not recommended
refer to the KYOCERA SGS Tool Wizard
®
for complete technical information (www.kyocera-sgstool.com)
