135 / 396
NON-FERROUS
PLASTICS/COMPOSITES
135
www.kyocera-sgstool.com
END MILLS
END MILLS
43CR
FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
CORNER
RADIUS
R
UNCOATED
Ti-NAMITE-B
(TiB
2
)
1/8
3/8
1-1/2
1/8
.010
34771
34793
3/16
9/16
2
3/16
.010
34772
34794
1/4
3/8
2-1/2
1/4
.010
35575
35665
1/4
3/8
2-1/2
1/4
.015
35576
35666
1/4
3/8
2-1/2
1/4
.030
35577
35667
1/4
3/8
2-1/2
1/4
.060
35578
35668
1/4
3/4
2-1/2
1/4
.010
34773
34795
1/4
3/4
2-1/2
1/4
.015
35579
35669
1/4
3/4
2-1/2
1/4
.030
34774
34796
1/4
3/4
2-1/2
1/4
.060
35580
35670
1/4
1
3
1/4
.010
35581
35671
1/4
1
3
1/4
.015
35582
35672
1/4
1
3
1/4
.030
35583
35673
1/4
1
3
1/4
.060
35584
35674
5/16
5/8
2-1/2
5/16
.030
34775
34797
3/8
1/2
3
3/8
.010
35585
35675
3/8
1/2
3
3/8
.015
35586
35676
3/8
1/2
3
3/8
.030
35587
35677
3/8
1/2
3
3/8
.060
35588
35678
3/8
1/2
3
3/8
.090
35589
35679
3/8
1
2-1/2
3/8
.010
34776
34798
3/8
1
2-1/2
3/8
.030
34777
34799
3/8
1
2-1/2
3/8
.060
32761
32825
3/8
1
3
3/8
.015
35590
35680
3/8
1
3
3/8
.090
35591
35681
3/8
1-1/2
4
3/8
.010
35592
35682
3/8
1-1/2
4
3/8
.015
35593
35683
3/8
1-1/2
4
3/8
.030
35594
35684
3/8
1-1/2
4
3/8
.060
35595
35685
3/8
1-1/2
4
3/8
.090
35596
35686
1/2
5/8
3
1/2
.010
35597
35687
1/2
5/8
3
1/2
.015
35598
35688
1/2
5/8
3
1/2
.030
35599
35689
1/2
5/8
3
1/2
.060
35600
35690
1/2
5/8
3
1/2
.090
35601
35691
1/2
5/8
3
1/2
.120
35602
35692
continued on next page
®
FRACTIONAL
S-Carb
®
• Circular land allows
for increased control
at various speed and
feed rates and reduces
chatter
• Symmetrical end
gashing for excellent
balance at high speeds
and aggressive plunging
capability
• Open fluting for deep
slotting and profiling
• Enhanced corner
geometry with tight
tolerance corner radii
• Recommended for
materials ≤ 150 Bhn
(≤ 7 HRc)
POS
3
TOLERANCES
(inch)
1/8–3/16
DIAMETER
D
1
=
+0.0000/–0.00032
D
2
=
h
6
R =
+0.0000/–0.0020
1/4–3/8
DIAMETER
D
1
=
+0.0000/–0.00035
D
2
=
h
6
R =
+0.0000/–0.0020
1/2–5/8
DIAMETER
D
1
=
+0.0000/–0.00043
D
2
=
h
6
R =
+0.0000/–0.0020
3/4–1
DIAMETER
D
1
=
+0.0000/–0.00051
D
2
=
h
6
R =
+0.0000/–0.0020
For patent
information visit
www.ksptpatents.com
