136 / 396
NON-FERROUS
PLASTICS/COMPOSITES
136
www.kyocera-sgstool.com
END MILLS
END MILLS
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
CORNER
RADIUS
R
UNCOATED
Ti-NAMITE-B
(TiB
2
)
1/2
1
3
1/2
.010
35603
35693
1/2
1
3
1/2
.015
35604
35694
1/2
1
3
1/2
.030
35605
35695
1/2
1
3
1/2
.060
35606
35696
1/2
1
3
1/2
.090
35607
35697
1/2
1
3
1/2
.120
35608
35698
1/2
1-1/4
3
1/2
.015
35609
35699
1/2
1-1/4
3-1/4
1/2
.010
34778
34800
1/2
1-1/4
3-1/4
1/2
.030
34779
34801
1/2
1-1/4
3-1/4
1/2
.060
34780
34802
1/2
1-1/4
3-1/4
1/2
.090
34781
34803
1/2
1-1/4
3-1/4
1/2
.120
32766
32830
1/2
1-5/8
4
1/2
.010
35610
35700
1/2
1-5/8
4
1/2
.015
35611
35701
1/2
1-5/8
4
1/2
.030
35612
35702
1/2
1-5/8
4
1/2
.060
35613
35703
1/2
1-5/8
4
1/2
.090
35614
35704
1/2
1-5/8
4
1/2
.120
35615
35705
1/2
2
4
1/2
.010
35616
35706
1/2
2
4
1/2
.015
35617
35707
1/2
2
4
1/2
.030
35618
35708
1/2
2
4
1/2
.060
35619
35709
1/2
2
4
1/2
.090
35620
35710
1/2
2
4
1/2
.120
35621
35711
5/8
3/4
3-1/2
5/8
.030
35622
35712
5/8
3/4
3-1/2
5/8
.060
35623
35713
5/8
3/4
3-1/2
5/8
.090
35624
35714
5/8
3/4
3-1/2
5/8
.120
35625
35715
5/8
1-5/8
3-3/4
5/8
.030
34782
34804
5/8
1-5/8
3-3/4
5/8
.060
34783
34805
5/8
1-5/8
3-3/4
5/8
.090
34784
34806
5/8
1-5/8
3-3/4
5/8
.120
35626
35716
3/4
1
4
3/4
.030
35627
35717
3/4
1
4
3/4
.060
35628
35718
3/4
1
4
3/4
.090
35629
35719
3/4
1
4
3/4
.120
35630
35720
continued on next page
FRACTIONAL
S-Carb
®
POS
3
CONTINUED
TOLERANCES
(inch)
1/8–3/16
DIAMETER
D
1
=
+0.0000/–0.00032
D
2
=
h
6
R =
+0.0000/–0.0020
1/4–3/8
DIAMETER
D
1
=
+0.0000/–0.00035
D
2
=
h
6
R =
+0.0000/–0.0020
1/2–5/8
DIAMETER
D
1
=
+0.0000/–0.00043
D
2
=
h
6
R =
+0.0000/–0.0020
3/4–1
DIAMETER
D
1
=
+0.0000/–0.00051
D
2
=
h
6
R =
+0.0000/–0.0020
43CR
FRACTIONAL SERIES
®
For patent
information visit
www.ksptpatents.com
