END MILLS
END MILLS
www.kyocera-sgstool.com
Main Key
★
Primary Function
Secondary Function
Coolant Required
Plunging NOT Recommended
Coating Key
Ti-Namite-A (TA) = AlTiN
Ti-Namite-X (TX) = Proprietary nanocomposite
Ti-Namite-M (TM) = AlTiSiN nanocomposite
Ti-Namite-B (TB) = TiB2
Di-Namite
®
= polycrystalline diamond
Rake Key
+ = Positive
– = Negative
0 = Neutral
Relief Key
E = Eccentric
P-S = Primary - Secondary
C = Concave
Center Cutting Key
Y = Yes
N = No
EM = End Mill End
DR = Drill End
Name
Series
Page
No.
Material
No.
Flutes
Helix °
Flute
Index Rake Relief
Center
Cutting
Steel
Stainless Steels
Cast Iron
High Temp Alloys
Titanium Alloys
Non Ferrous
Plastics, Composites
Hardened Steels
Z-Carb HPR
Z5
28
★ ★ ★ ★ ★
5
37
≠
+
E
N
Z-Carb
Z1 / Z16 / Z1B 47
★ ★ ★ ★
4
35 / 38
≠
+
E
Y
Z-Carb-AP
Z1P
36
★ ★ ★ ★
4
35 / 38
≠
+
E
Y
Z-Carb-HTA
ZH1
56
★
4
38 / 41
≠
+
E
Y
Z-Carb-MD
ZD1
60
★
★
4
42 / 45
≠
–
E
Y
Series 33
33
94
★ ★ ★ ★
3
32 / 48
≠
+
E
Y
T-Carb
®
51
75
★ ★ ★ ★
6
41
≠
+
E
Y
Series 7
7
100
★ ★ ★ ★ ★
4
38
≠
+
P-S
Y
V-Carb
55
63
★ ★ ★ ★ ★
5
45
≠
+
P-S
Y
Multi-Carb
66
86
★ ★
★
7, 9, 11
35
=
+
E
N
Turbo-Carb
56B 106
★
★
2
30
=
+
E
Y
Power-Carb
57
110
★
6
45
=
–
E
Y
Ski-Carb
44, 45
164
★
2
45
=
+
P-S
Y
S-Carb
®
3 Flute
43
134
★
3
38
=
+
E
Y
S-Carb
®
Chipbreaker
43CB 144
★
3
38
=
+
E
Y
S-Carb
®
2 Flute
47
157
★
2
35
=
+
E
Y
S-Carb APR
®
43APR 123
★
3
38
=
+
E
Y
S-Carb APR-3
®
APR3
129
★
3
38
≠
+
E
Y
S-Carb APR-4
®
APR4
130
★
4
38 / 41
≠
+
E
Y
S-Carb APF
®
43APF
125
★
4
38 / 41
≠
+
E
Y
Slow Helix
27
114
★
4
10 / 12
≠
+
P-S
Y
CCR *
20-CCR 356
★
8, 10, 12
15
=
+
C EM or DR
CCR *
31-CCR 362
★
5, 7, 10
15
=
+
C EM or DR
PCR *
29-PCR 352
★
8, 9, 12
15
=
0
E EM or DR
Compression Router
25
366
★
4, 6, 8
30
=
+
P-S
Y
Up Cut Router
21
370
★
2
35
=
+
P-S
Y
Down Cut Router
22
371
★
2
35
=
+
P-S
Y
End Mill Matrix
