STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
28
www.kyocera-sgstool.com
END MILLS
END MILLS
Z5
FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
TI-NAMITE-A
(TA)
TI-NAMITE-A
(TA)
W/FLAT
TI-NAMITE-A
(TA)
W/INTERNAL
COOLANT
TI-NAMITE-M
(TM)
TI-NAMITE-M
(TM)
W/ FLAT
TI-NAMITE-M
(TM)
W/INTERNAL
COOLANT
1/8 1/4 1-1/2 1/8
–
–
–
37000
–
–
1/8 3/8 1-1/2 1/8 37180
–
–
37002
–
–
3/16 5/16 2 3/16
–
–
–
37004
–
–
3/16 1/2
2 3/16 37182
–
–
37006
–
–
1/4 3/8 2-1/2 1/4 38502
–
–
37008
–
–
1/4 1/2 2-1/2 1/4 37184
–
–
37011
–
–
5/16 7/16 2-1/2 5/16
–
–
–
37014
–
–
5/16 5/8 2-1/2 5/16 38504
–
–
37016
–
–
3/8 1/2 2-1/2 3/8
–
–
–
37018
–
–
3/8 3/4 2-1/2 3/8 37187
–
–
37021
–
–
7/16 5/8
2-1/2 7/16 37168
–
–
37159
–
–
7/16 7/8
2-3/4 7/16 37170
–
–
37169
–
–
1/2 5/8
3
1/2 38506 38512 37320 37024 37030 37321
1/2
1
3
1/2 38507 38513 37322 37036 37042 37323
1/2 1-1/4 3-1/4 1/2 37190 37194 37324 37048 37054 37325
5/8 3/4 3-1/2 5/8 38508 38514
–
37060 37067 37260
5/8 1-1/4 3-1/2 5/8 37198 37202
–
37074 37081 37267
3/4 7/8
4
3/4
–
38515
–
37088 37095 37274
3/4 1-1/2 4
3/4 37206 37210
–
37102 37109 37281
1 1-1/8 4
1
–
–
–
37116 37123 37288
1 1-1/2 4
1
37214 37218
–
37130 37137 37295
1
2 4-1/2 1
–
38517
–
37144 37151 37302
FRACTIONAL
Z-Carb-HPR
≠
POS
5
TOLERANCES
(inch)
1/8–1/4
DIAMETER
D
1
=
+0.0000/–0.0012
D
2
=
h
6
>1/4–3/8
DIAMETER
D
1
=
+0.0000/–0.0016
D
2
=
h
6
>3/8–1
DIAMETER
D
1
=
+0.0000/–0.0020
D
2
=
h
6
• An ideal balance of helix,
indexing, flute depth,
rake and relief
• Variable indexing for
chatter supression
and proprietary edge
geometry for shearing
and strength
• Chatter-free geometry
allows deep cutting and
high speed machining
• Central coolant hole
delivers coolant
effectively to the cutting
zone enhancing chip
removal when pocketing
or slotting
• Excels at roughing,
ramping, high speed
machining and finishing
in a variety of materials
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
2
D
1
D
L
1
L
2
37°
For patent
information visit
www.ksptpatents.com
