224 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
NON-FERROUS
PLASTICS/COMPOSITES
224
www.kyocera-sgstool.com
1MCR
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
CORNER
RADIUS
R
SHANK
DIAMETER
D
2
Ti-NAMITE-A
(AlTiN)
4,0
14,0
50,0
0,25
4,0
40000
4,0
14,0
50,0
0,50
4,0
40001
4,0
14,0
50,0
1,00
4,0
40003
5,0
16,0
50,0
0,25
6,0
40004
5,0
16,0
50,0
0,50
6,0
40005
5,0
16,0
50,0
1,00
6,0
40007
6,0
19,0
50,0
0,25
6,0
40009
6,0
19,0
50,0
0,50
6,0
40010
6,0
19,0
50,0
0,75
6,0
40011
6,0
19,0
50,0
1,00
6,0
40012
8,0
20,0
63,0
0,50
8,0
40015
8,0
20,0
63,0
0,75
8,0
40016
8,0
20,0
63,0
1,00
8,0
40017
8,0
20,0
63,0
1,50
8,0
40019
8,0
20,0
63,0
2,00
8,0
40020
10,0
22,0
75,0
0,50
10,0
40021
10,0
22,0
75,0
1,00
10,0
40023
10,0
22,0
75,0
1,50
10,0
40024
10,0
22,0
75,0
2,00
10,0
40025
12,0
25,0
75,0
0,50
12,0
40028
12,0
25,0
75,0
1,00
12,0
40030
12,0
25,0
75,0
1,50
12,0
40031
12,0
25,0
75,0
2,00
12,0
40032
16,0
32,0
89,0
0,50
16,0
40035
16,0
32,0
89,0
1,00
16,0
40037
16,0
32,0
89,0
1,50
16,0
40038
16,0
32,0
89,0
2,00
16,0
40039
METRIC
4 Flute Corner Radius
TOLERANCES
(mm)
D
1
=
+0,000/–0,050
D
2
=
h
6
R =
+0,000/–0,050
POS
4
For patent
information visit
www.ksptpatents.com
