223 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
NON-FERROUS
PLASTICS/COMPOSITES
223
www.kyocera-sgstool.com
1M
•
1XLM
METRIC SERIES
mm
EDP NO.
SERIES
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED
Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
1,0
4,0
38,0
3,0
40105
48500
48522
48543
1M
1,5
4,5
38,0
3,0
40109
48501
48523
48544
1M
2,0
6,3
38,0
3,0
40113
48502
48524
48545
1M
2,5
9,5
38,0
3,0
40117
48503
48525
48546
1M
3,0
12,0
38,0
3,0
40121
48504
48526
48547
1M
3,0
25,0
75,0
3,0
43101
49388
49401
49414 1XLM
3,5
12,0
50,0
4,0
40125
48505
48527
48548
1M
4,0
14,0
50,0
4,0
40129
48506
48528
48549
1M
4,0
25,0
75,0
4,0
43103
49389
49402
49415 1XLM
4,5
16,0
50,0
6,0
40133
48507
48529
48550
1M
5,0
16,0
50,0
6,0
40137
48508
48530
48551
1M
5,0
25,0
75,0
5,0
43107
49391
49404
49417 1XLM
6,0
19,0
50,0
6,0
40141
48509
48531
48552
1M
6,0
25,0
75,0
6,0
43105
49390
49403
49416 1XLM
7,0
19,0
63,0
8,0
40145
48510
48532
48553
1M
8,0
20,0
63,0
8,0
40149
48511
48533
48554
1M
8,0
25,0
75,0
8,0
43115
49392
49405
49418 1XLM
9,0
22,0
75,0
10,0
40153
48512
48534
48555
1M
10,0
22,0
75,0
10,0
40157
48513
48535
48556
1M
10,0
38,0
100,0
10,0
43125
49393
49406
49419 1XLM
11,0
25,0
75,0
12,0
40161
48514
48536
48557
1M
12,0
25,0
75,0
12,0
41665
48515
48537
48558
1M
12,0
50,0
100,0
12,0
43135
49394
49407
49420 1XLM
12,0
75,0
150,0
12,0
43145
49395
49408
49421 1XLM
14,0
32,0
89,0
14,0
40169
48516
48538
48559
1M
14,0
75,0
150,0
14,0
43155
49396
49409
49422 1XLM
16,0
32,0
89,0
16,0
40173
48517
48539
48560
1M
16,0
75,0
150,0
16,0
43165
49397
49410
49423 1XLM
18,0
38,0
100,0
18,0
40177
48518
48540
48561
1M
18,0
75,0
150,0
18,0
43175
49398
49411
49424 1XLM
20,0
38,0
100,0
20,0
40181
48519
48541
48562
1M
20,0
75,0
150,0
20,0
43185
49399
49412
49425 1XLM
25,0
38,0
100,0
25,0
40185
48520
48542
48563
1M
25,0
75,0
150,0
25,0
43195
49400
49413
49426 1XLM
METRIC
4 Flute End Mills
POS
4
TOLERANCES
(mm)
D
1
=
+0,000/–0,050
D
2
=
h
6
For patent
information visit
www.ksptpatents.com
