STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
NON-FERROUS
PLASTICS/COMPOSITES
225
www.kyocera-sgstool.com
14M
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
1,0
2,0
38,0
3,0
41405
48884
48905
48926
1,5
3,0
38,0
3,0
41409
48885
48906
48927
2,0
4,0
38,0
3,0
41413
48886
48907
48928
2,5
5,0
38,0
3,0
41417
48887
48908
48929
3,0
6,0
38,0
3,0
41421
48888
48909
48930
3,5
7,0
50,0
4,0
41425
48889
48910
48931
4,0
8,0
50,0
4,0
41429
48890
48911
48932
4,5
9,5
63,0
4,5
41433
48891
48912
48933
5,0
10,0
63,0
5,0
41437
48892
48913
48934
6,0
12,0
63,0
6,0
41441
48893
48914
48935
7,0
12,0
63,0
8,0
41445
48894
48915
48936
8,0
12,0
63,0
8,0
41449
48895
48916
48937
9,0
14,0
75,0
9,0
41453
48896
48917
48938
10,0
14,0
75,0
10,0
41457
48897
48918
48939
11,0
14,0
75,0
12,0
41461
48898
48919
48940
12,0
16,0
75,0
12,0
41465
48899
48920
48941
METRIC
4 Flute Double End Mills
POS
4
TOLERANCES
(mm)
D
1
=
+0,000/–0,050
D
2
=
h
6
For patent
information visit
www.ksptpatents.com
