222 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
NON-FERROUS
PLASTICS/COMPOSITES
222
www.kyocera-sgstool.com
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED
Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
1,0
2,0
38,0
3,0
41605
49136
49157
49178
1,5
3,0
38,0
3,0
41609
49137
49158
49179
2,0
4,0
38,0
3,0
41613
49138
49159
49180
2,5
5,0
38,0
3,0
41617
49139
49160
49181
3,0
6,0
38,0
3,0
41621
49140
49161
49182
3,5
7,0
50,0
4,0
41625
49141
49162
49183
4,0
8,0
50,0
4,0
41629
49142
49163
49184
4,5
9,5
50,0
4,5
41633
49143
49164
49185
5,0
10,0
50,0
5,0
41637
49144
49165
49186
6,0
12,0
50,0
6,0
41641
49145
49166
49187
7,0
12,0
50,0
8,0
41645
49146
49167
49188
8,0
12,0
50,0
8,0
41649
49147
49168
49189
9,0
14,0
50,0
9,0
41653
49148
49169
49190
10,0
16,0
50,0
10,0
41657
49149
49170
49191
11,0
19,0
63,0
12,0
41661
49150
49171
49192
12,0
19,0
63,0
12,0
40165
49151
49172
49193
METRIC
4 Flute Square End Stub
TOLERANCES
(mm)
D
1
=
+0,000/–0,050
D
2
=
h
6
POS
4
16M
METRIC SERIES
For patent
information visit
www.ksptpatents.com
