DRILLS
DRILLS
2
D
L
1
L
2
L
3
L
4
124°
30°
1
D
264
www.kyocera-sgstool.com
CUTTING
DIA.
D
1
DECIMAL
EQUIV.
METRIC
EQUIV.
TAP SIZE
REFERENCE
ONLY
SHANK
DIA.
D
2
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
CLEARED
LENGTH
L
3
SHANK
LENGTH
L
4
UNCOATED
EDP NO.
Ti-NAMITE-B
(TiB
2
)
EDP NO.
3,0 mm 0.1181
6,0 62,0 20,0 14,0 36,0 64600
67600
3,1 mm 0.1220
6,0 62,0 20,0 14,0 36,0 64601
67601
1/8 0.1250 3.18
6,0 62,0 20,0 14,0 36,0 54600
54700
3,2 mm 0.1260
M3,5 X 0,35
6,0 62,0 20,0 14,0 36,0 64602
67602
3,3 mm 0.1299
M4 X 0,7
6,0 62,0 20,0 14,0 36,0 64603
67603
3,4 mm 0.1339
6,0 62,0 20,0 14,0 36,0 64604
67604
#29 0.1360 3.45
8-32,8-36
6,0 62,0 20,0 14,0 36,0 54601
54701
3,5 mm 0.1378
M4 X 0,5
6,0 62,0 20,0 14,0 36,0 64605
67605
9/64 0.1406 3.57
6,0 62,0 20,0 14,0 36,0 54602
54702
3,6 mm 0.1417
M4 X 0,35
6,0 62,0 20,0 14,0 36,0 64606
67606
3,7 mm 0.1457
M4,5 X 0,75
6,0 62,0 20,0 14,0 36,0 64607
67607
3,8 mm 0.1496
10-24
6,0 66,0 24,0 17,0 36,0 64608
67608
3,9 mm 0.1535
6,0 66,0 24,0 17,0 36,0 64609
67609
5/32 0.1562 3.97
6,0 66,0 24,0 17,0 36,0 54603
54703
4,0 mm 0.1575
M4,5 X 0,5
6,0 66,0 24,0 17,0 36,0 64610
67610
#21 0.1590 4.04
10-32
6,0 66,0 24,0 17,0 36,0 54604
54704
4,1 mm 0.1614
6,0 66,0 24,0 17,0 36,0 64611
67611
4,2 mm 0.1654
M5 / M5 x 0,75 6,0 66,0 24,0 17,0 36,0 64612
67612
4,3 mm 0.1693
6,0 66,0 24,0 17,0 36,0 64613
67613
11/64 0.1719 4.37
6,0 66,0 24,0 17,0 36,0 54605
54705
4,4 mm 0.1732
12-24
6,0 66,0 24,0 17,0 36,0 64614
67614
4,5 mm 0.1772
M5 X 0,5
6,0 66,0 24,0 17,0 36,0 64615
67615
4,6 mm 0.1811
12-28
6,0 66,0 24,0 17,0 36,0 64616
67616
4,7 mm 0.1850
12-32
6,0 66,0 24,0 17,0 36,0 64617
67617
3/16 0.1875 4.76
6,0 66,0 28,0 20,0 36,0 54606
54706
4,8 mm 0.1890
7/32-32
6,0 66,0 28,0 20,0 36,0 64618
67618
4,9 mm 0.1929
6,0 66,0 28,0 20,0 36,0 64619
67619
5,0 mm 0.1969
M6 X 1
6,0 66,0 28,0 20,0 36,0 64620
67620
5,1 mm 0.2008
1/4-20
6,0 66,0 28,0 20,0 36,0 64621
67621
13/64 0.2031 5.16
6,0 66,0 28,0 20,0 36,0 54607
54707
5,2 mm 0.2047
M6 X 0,75
6,0 66,0 28,0 20,0 36,0 64622
67622
5,3 mm 0.2087
6,0 66,0 28,0 20,0 36,0 64623
67623
5,4 mm 0.2126
6,0 66,0 28,0 20,0 36,0 64624
67624
5,5 mm 0.2165
M6 X 0,5
6,0 66,0 28,0 20,0 36,0 64625
67625
7/32 0.2188 5.56
1/4-32
6,0 66,0 28,0 20,0 36,0 54608
54708
5,6 mm 0.2205
6,0 66,0 28,0 20,0 36,0 64626
67626
continued on next page
FRACTIONAL & METRIC
Hi-PerCarb
131N 3xD
FRACTIONAL & METRIC SERIES
3
• Triple margin design
improves hole stability
and size control while
providing superior
finish, roundness and
cylindricity
• Self-stabilizing pyramid
point design stabilizes
the drill on contact with
the workpiece
• Open flute structure
efficiently transports
chips while maintaining
strength at high
feed rates
• Sculpted gash allows
chips to easily flow away
from the drill center
• Recommended for
materials ≤ 175 Bhn
(≤ 16 HRc)
NON-FERROUS
PLASTICS/COMPOSITES
TOLERANCES
(mm)
≤3
DIAMETER
D
1
=
+0,002/+0,012
D
2
=
h
6
>3–6
DIAMETER
D
1
=
+0,004/+0,016
D
2
=
h
6
>6–10
DIAMETER
D
1
=
+0,006/+0,021
D
2
=
h
6
>10–18
DIAMETER
D
1
=
+0,007/+0,025
D
2
=
h
6
TOLERANCES
(inch)
≤.1181
DIAMETER
D
1
=
+.00008/+.00047
D
2
=
h
6
>.1181–.2362
DIAMETER
D
1
=
+.00016/+.00063
D
2
=
h
6
>.2362–.3937
DIAMETER
D
1
=
+.00024/+.00083
D
2
=
h
6
>.3937–.7087
DIAMETER
D
1
=
+.00028/+.00098
D
2
=
h
6
>.7087–1.1811
DIAMETER
D
1
=
+.00031/+.00114
D
2
=
h
6
For patent
information visit
www.ksptpatents.com
