266 / 396
DRILLS
DRILLS
2
D
L
1
L
2
L
3
L
4
124°
30°
1
D
266
www.kyocera-sgstool.com
CUTTING
DIA.
D
1
DECIMAL
EQUIV.
METRIC
EQUIV.
TAP SIZE
REFERENCE
ONLY
SHANK
DIA.
D
2
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
CLEARED
LENGTH
L
3
SHANK
LENGTH
L
4
UNCOATED
EDP NO.
Ti-NAMITE-B
(TiB
2
)
EDP NO.
9,2 mm 0.3622
M10 X 0,75 10,0 89,0 47,0 35,0 40,0 64662
67662
9,3 mm 0.3661
10,0 89,0 47,0 35,0 40,0 64663
67663
U 0.3680 9.35
7/16-14
10,0 89,0 47,0 35,0 40,0 54620
54720
9,4 mm 0.3701
10,0 89,0 47,0 35,0 40,0 64664
67664
9,5 mm 0.3740
M11 / M10 X 0,5 10,0 89,0 47,0 35,0 40,0 64665
67665
3/8 0.3750 9.53
10,0 89,0 47,0 35,0 40,0 54621
54721
9,6 mm 0.3780
10,0 89,0 47,0 35,0 40,0 64666
67666
9,7 mm 0.3819
10,0 89,0 47,0 35,0 40,0 64667
67667
9,8 mm 0.3858
10,0 89,0 47,0 35,0 40,0 64668
67668
9,9 mm 0.3898
10,0 89,0 47,0 35,0 40,0 64669
67669
25/64 0.3906 9.92
7/16-20
10,0 89,0 47,0 35,0 40,0 54622
54722
10,0 mm 0.3937
10,0 89,0 47,0 35,0 40,0 64670
67670
10,1 mm 0.3976
12,0 102,0 55,0 40,0 45,0 64671
67671
10,2 mm 0.4016
M12 X 1,75 12,0 102,0 55,0 40,0 45,0 64672
67672
10,3 mm 0.4055
12,0 102,0 55,0 40,0 45,0 64673
67673
13/32 0.4062 10.32
12,0 102,0 55,0 40,0 45,0 54623
54723
10,4 mm 0.4094
12,0 102,0 55,0 40,0 45,0 64674
67674
10,5 mm 0.4134
M12 X 1,5
12,0 102,0 55,0 40,0 45,0 64675
67675
10,6 mm 0.4173
12,0 102,0 55,0 40,0 45,0 64676
67676
10,7 mm 0.4213
12,0 102,0 55,0 40,0 45,0 64677
67677
27/64 0.4219 10.72
1/2-13
12,0 102,0 55,0 40,0 45,0 54624
54724
10,8 mm 0.4252
M12 X 1,25 12,0 102,0 55,0 40,0 45,0 64678
67678
10,9 mm 0.4291
12,0 102,0 55,0 40,0 45,0 64679
67679
11,0 mm 0.4331
M12 X 1
12,0 102,0 55,0 40,0 45,0 64680
67680
11,1 mm 0.4370
12,0 102,0 55,0 40,0 45,0 64681
67681
7/16 0.4375 11.11 1/4-18NPT 12,0 102,0 55,0 40,0 45,0 54625
54725
11,2 mm 0.4409
12,0 102,0 55,0 40,0 45,0 64682
67682
11,3 mm 0.4449
12,0 102,0 55,0 40,0 45,0 64683
67683
11,4 mm 0.4488
12,0 102,0 55,0 40,0 45,0 64684
67684
11,5 mm 0.4528
M12 X 0,5
12,0 102,0 55,0 40,0 45,0 64685
67685
11,6 mm 0.4567
12,0 102,0 55,0 40,0 45,0 64686
67686
11,7 mm 0.4606
12,0 102,0 55,0 40,0 45,0 64687
67687
11,8 mm 0.4646
12,0 102,0 55,0 40,0 45,0 64688
67688
11,9 mm 0.4685
12,0 102,0 55,0 40,0 45,0 64689
67689
15/32 0.4688 11.91
1/2-28
12,0 102,0 55,0 40,0 45,0 54626
54726
12,0 mm 0.4724
M14 X 2
12,0 102,0 55,0 40,0 45,0 64690
67690
continued on next page
FRACTIONAL & METRIC
Hi-PerCarb
131N 3xD
FRACTIONAL & METRIC SERIES
3
• Triple margin design
improves hole stability
and size control while
providing superior
finish, roundness and
cylindricity
• Self-stabilizing pyramid
point design stabilizes
the drill on contact with
the workpiece
• Open flute structure
efficiently transports
chips while maintaining
strength at high
feed rates
• Sculpted gash allows
chips to easily flow away
from the drill center
• Recommended for
materials ≤ 175 Bhn
(≤ 16 HRc)
NON-FERROUS
PLASTICS/COMPOSITES
TOLERANCES
(mm)
≤3
DIAMETER
D
1
=
+0,002/+0,012
D
2
=
h
6
>3–6
DIAMETER
D
1
=
+0,004/+0,016
D
2
=
h
6
>6–10
DIAMETER
D
1
=
+0,006/+0,021
D
2
=
h
6
>10–18
DIAMETER
D
1
=
+0,007/+0,025
D
2
=
h
6
TOLERANCES
(inch)
≤.1181
DIAMETER
D
1
=
+.00008/+.00047
D
2
=
h
6
>.1181–.2362
DIAMETER
D
1
=
+.00016/+.00063
D
2
=
h
6
>.2362–.3937
DIAMETER
D
1
=
+.00024/+.00083
D
2
=
h
6
>.3937–.7087
DIAMETER
D
1
=
+.00028/+.00098
D
2
=
h
6
>.7087–1.1811
DIAMETER
D
1
=
+.00031/+.00114
D
2
=
h
6
For patent
information visit
www.ksptpatents.com
