265 / 396
DRILLS
DRILLS
265
www.kyocera-sgstool.com
CUTTING
DIA.
D
1
DECIMAL
EQUIV.
METRIC
EQUIV.
TAP SIZE
REFERENCE
ONLY
SHANK
DIA.
D
2
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
CLEARED
LENGTH
L
3
SHANK
LENGTH
L
4
UNCOATED
EDP NO.
Ti-NAMITE-B
(TiB
2
)
EDP NO.
5,7 mm 0.2244
6,0 66,0 28,0 20,0 36,0 64627
67627
5,8 mm 0.2283
6,0 66,0 28,0 20,0 36,0 64628
67628
5,9 mm 0.2323
6,0 66,0 28,0 20,0 36,0 64629
67629
15/64 0.2344 5.95
6,0 66,0 28,0 20,0 36,0 54609
54709
6,0 mm 0.2362
M7 X 1
6,0 66,0 28,0 20,0 36,0 64630
67630
6,1 mm 0.2402
8,0 79,0 34,0 24,0 36,0 64631
67631
6,2 mm 0.2441
M7 X 0,75
8,0 79,0 34,0 24,0 36,0 64632
67632
6,3 mm 0.2480
8,0 79,0 34,0 24,0 36,0 64633
67633
1/4 0.2500 6.35
8,0 79,0 34,0 24,0 36,0 54610
54710
6,4 mm 0.2520
8,0 79,0 34,0 24,0 36,0 64634
67634
6,5 mm 0.2559
8,0 79,0 34,0 24,0 36,0 64635
67635
F
0.2570 6.53
5/16-18
8,0 79,0 34,0 24,0 36,0 54611
54711
6,6 mm 0.2598
8,0 79,0 34,0 24,0 36,0 64636
67636
6,7 mm 0.2638
8,0 79,0 34,0 24,0 36,0 64637
67637
17/64 0.2656 6.75
5/16-20
8,0 79,0 34,0 24,0 36,0 54612
54712
6,8 mm 0.2677
M8 X 1,25
8,0 79,0 34,0 24,0 36,0 64638
67638
6,9 mm 0.2717
5/16-24
8,0 79,0 34,0 24,0 36,0 64639
67639
7,0 mm 0.2756
M8 X 1
8,0 79,0 34,0 24,0 36,0 64640
67640
7,1 mm 0.2795
8,0 79,0 41,0 29,0 36,0 64641
67641
9/32 0.2812 7.14
5/16-32
8,0 79,0 41,0 29,0 36,0 54613
54713
7,2 mm 0.2835
M8 X 0,75
8,0 79,0 41,0 29,0 36,0 64642
67642
7,3 mm 0.2874
8,0 79,0 41,0 29,0 36,0 64643
67643
7,4 mm 0.2913
8,0 79,0 41,0 29,0 36,0 64644
67644
7,5 mm 0.2953
M8 X 0,5
8,0 79,0 41,0 29,0 36,0 64645
67645
19/64 0.2969 7.54
8,0 79,0 41,0 29,0 36,0 54614
54714
7,6 mm 0.2992
8,0 79,0 41,0 29,0 36,0 64646
67646
7,7 mm 0.3031
8,0 79,0 41,0 29,0 36,0 64647
67647
7,8 mm 0.3071
M9 X 1,25
8,0 79,0 41,0 29,0 36,0 64648
67648
7,9 mm 0.3110
8,0 79,0 41,0 29,0 36,0 64649
67649
5/16 0.3125 7.94
3/8-16
8,0 79,0 41,0 29,0 36,0 54615
54715
8,0 mm 0.3150
M9 X 1
8,0 79,0 41,0 29,0 36,0 64650
67650
8,1 mm 0.3189
10,0 89,0 47,0 35,0 40,0 64651
67651
8,2 mm 0.3228
10,0 89,0 47,0 35,0 40,0 64652
67652
8,3 mm 0.3268
10,0 89,0 47,0 35,0 40,0 64653
67653
21/64 0.3281 8.33
3/8-20
10,0 89,0 47,0 35,0 40,0 54616
54716
8,4 mm 0.3307
10,0 89,0 47,0 35,0 40,0 64654
67654
Q 0.3320 8.43
3/8-24
10,0 89,0 47,0 35,0 40,0 54617
54717
8,5 mm 0.3346
M10 X 1,5
10,0 89,0 47,0 35,0 40,0 64655
67655
8,6 mm 0.3386
10,0 89,0 47,0 35,0 40,0 64656
67656
8,7 mm 0.3425
10,0 89,0 47,0 35,0 40,0 64657
67657
11/32 0.3438 8.73
3/8-32
10,0 89,0 47,0 35,0 40,0 54618
54718
8,8 mm 0.3465
M10 X 1,25 10,0 89,0 47,0 35,0 40,0 64658
67658
8,9 mm 0.3504
10,0 89,0 47,0 35,0 40,0 64659
67659
9,0 mm 0.3543
M10 X 1
10,0 89,0 47,0 35,0 40,0 64660
67660
9,1 mm 0.3583
10,0 89,0 47,0 35,0 40,0 64661
67661
23/64 0.3594 9.13
10,0 89,0 47,0 35,0 40,0 54619
54719
continued on next page
FRACTIONAL & METRIC
Hi-PerCarb
CONTINUED
131N 3xD
FRACTIONAL & METRIC SERIES
