269 / 396
DRILLS
DRILLS
269
www.kyocera-sgstool.com
CUTTING
DIA.
D
1
DECIMAL
EQUIV.
METRIC
EQUIV.
TAP SIZE
REFERENCE
ONLY
SHANK
DIA.
D
2
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
CLEARED
LENGTH
L
3
SHANK
LENGTH
L
4
UNCOATED
EDP NO.
Ti-NAMITE-B
(TiB
2
)
EDP NO.
5,7 mm 0.2244
6,0 82,0 44,0 35,0 36,0 65027
64827
5,8 mm 0.2283
6,0 82,0 44,0 35,0 36,0 65028
64828
5,9 mm 0.2323
6,0 82,0 44,0 35,0 36,0 65029
64829
15/64 0.2344 5.95
6,0 82,0 44,0 35,0 36,0 55009
54809
6,0 mm 0.2362
M7 X 1
6,0 82,0 44,0 35,0 36,0 65030
64830
6,1 mm 0.2402
8,0 91,0 53,0 43,0 36,0 65031
64831
6,2 mm 0.2441
M7 X 0,75
8,0 91,0 53,0 43,0 36,0 65032
64832
6,3 mm 0.2480
8,0 91,0 53,0 43,0 36,0 65033
64833
1/4 0.2500 6.35
8,0 91,0 53,0 43,0 36,0 55010
54810
6,4 mm 0.2520
8,0 91,0 53,0 43,0 36,0 65034
64834
6,5 mm 0.2559
8,0 91,0 53,0 43,0 36,0 65035
64835
F
0.2570 6.53
5/16-18
8,0 91,0 53,0 43,0 36,0 55011
54811
6,6 mm 0.2598
8,0 91,0 53,0 43,0 36,0 65036
64836
6,7 mm 0.2638
8,0 91,0 53,0 43,0 36,0 65037
64837
17/64 0.2656 6.75
5/16-20
8,0 91,0 53,0 43,0 36,0 55012
54812
6,8 mm 0.2677
M8 X 1,25
8,0 91,0 53,0 43,0 36,0 65038
64838
6,9 mm 0.2717
5/16-24
8,0 91,0 53,0 43,0 36,0 65039
64839
7,0 mm 0.2756
M8 X 1
8,0 91,0 53,0 43,0 36,0 65040
64840
7,1 mm 0.2795
8,0 91,0 53,0 43,0 36,0 65041
64841
9/32 0.2812 7.14
5/16-32
8,0 91,0 53,0 43,0 36,0 55013
54813
7,2 mm 0.2835
M8 X 0,75
8,0 91,0 53,0 43,0 36,0 65042
64842
7,3 mm 0.2874
8,0 91,0 53,0 43,0 36,0 65043
64843
7,4 mm 0.2913
8,0 91,0 53,0 43,0 36,0 65044
64844
7,5 mm 0.2953
M8 X 0,5
8,0 91,0 53,0 43,0 36,0 65045
64845
19/64 0.2969 7.54
8,0 91,0 53,0 43,0 36,0 55014
54814
7,6 mm 0.2992
8,0 91,0 53,0 43,0 36,0 65046
64846
7,7 mm 0.3031
8,0 91,0 53,0 43,0 36,0 65047
64847
7,8 mm 0.3071
M9 X 1,25
8,0 91,0 53,0 43,0 36,0 65048
64848
7,9 mm 0.3110
8,0 91,0 53,0 43,0 36,0 65049
64849
5/16 0.3125 7.94
3/8-16
8,0 91,0 53,0 43,0 36,0 55015
54815
8,0 mm 0.3150
M9 X 1
8,0 91,0 53,0 43,0 36,0 65050
64850
8,1 mm 0.3189
10,0 103,0 61,0 49,0 40,0 65051
64851
8,2 mm 0.3228
10,0 103,0 61,0 49,0 40,0 65052
64852
8,3 mm 0.3268
10,0 103,0 61,0 49,0 40,0 65053
64853
21/64 0.3281 8.33
3/8-20
10,0 103,0 61,0 49,0 40,0 55016
54816
8,4 mm 0.3307
10,0 103,0 61,0 49,0 40,0 65054
64854
Q 0.3320 8.43
3/8-24
10,0 103,0 61,0 49,0 40,0 55017
54817
8,5 mm 0.3346
M10 X 1,5
10,0 103,0 61,0 49,0 40,0 65055
64855
8,6 mm 0.3386
10,0 103,0 61,0 49,0 40,0 65056
64856
8,7 mm 0.3425
10,0 103,0 61,0 49,0 40,0 65057
64857
11/32 0.3438 8.73
3/8-32
10,0 103,0 61,0 49,0 40,0 55018
54818
8,8 mm 0.3465
M10 X 1,25 10,0 103,0 61,0 49,0 40,0 65058
64858
8,9 mm 0.3504
10,0 103,0 61,0 49,0 40,0 65059
64859
9,0 mm 0.3543
M10 X 1
10,0 103,0 61,0 49,0 40,0 65060
64860
9,1 mm 0.3583
10,0 103,0 61,0 49,0 40,0 65061
64861
23/64 0.3594 9.13
10,0 103,0 61,0 49,0 40,0 55019
54819
continued on next page
FRACTIONAL & METRIC
Hi-PerCarb
CONTINUED
131N 5xD
FRACTIONAL & METRIC SERIES
