267 / 396
DRILLS
DRILLS
267
www.kyocera-sgstool.com
CUTTING
DIA.
D
1
DECIMAL
EQUIV.
METRIC
EQUIV.
TAP SIZE
REFERENCE
ONLY
SHANK
DIA.
D
2
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
CLEARED
LENGTH
L
3
SHANK
LENGTH
L
4
UNCOATED
EDP NO.
Ti-NAMITE-B
(TiB
2
)
EDP NO.
31/64 0.4844 12.30
9/16-12
14,0 107,0 60,0 43,0 45,0 54627
54727
12,5 mm 0.4921
M14 X 1,5
14,0 107,0 60,0 43,0 45,0 64691
67691
1/2 0.5000 12.70
14,0 107,0 60,0 43,0 45,0 54628
54728
12,8 mm 0.5039
M14 X 1,25 14,0 107,0 60,0 43,0 45,0 64692
67692
13,0 mm 0.5118
M14 X 1
14,0 107,0 60,0 43,0 45,0 64693
67693
33/64 0.5156 13.10
9/16-18
14,0 107,0 60,0 43,0 45,0 54629
54729
13,5 mm 0.5315
5/8-11
14,0 107,0 60,0 43,0 45,0 64694
67694
13,8 mm 0.5433
14,0 107,0 60,0 43,0 45,0 64695
67695
14,0 mm 0.5512
M16 X 2
14,0 107,0 60,0 43,0 45,0 64696
67696
9/16 0.5625 14.29
16,0 115,0 65,0 45,0 48,0 54630
54730
14,5 mm 0.5709
M16 X 1,5
16,0 115,0 65,0 45,0 48,0 64697
67697
37/64 0.5781 14.68
5/8-18
16,0 115,0 65,0 45,0 48,0 54631
54731
14,8 mm 0.5827
16,0 115,0 65,0 45,0 48,0 64698
67698
15,0 mm 0.5906
M16 X 1
16,0 115,0 65,0 45,0 48,0 64699
67699
15,5 mm 0.6102
M18 X 2,5
16,0 115,0 65,0 45,0 48,0 64700
67700
15,8 mm 0.6220
16,0 115,0 65,0 45,0 48,0 64701
67701
5/8 0.6250 15.88
11/16-16
16,0 115,0 65,0 45,0 48,0 54632
54732
16,0 mm 0.6299
16,0 115,0 65,0 45,0 48,0 64702
67702
21/32 0.6562 16.67
3/4-10
18,0 123,0 73,0 51,0 48,0 54633
54733
11/16 0.6875 17.46
3/4-16
18,0 123,0 73,0 51,0 48,0 54634
54734
3/4 0.7500 19.05
13/16-16
20,0 131,0 79,0 55,0 50,0 54635
54735
FRACTIONAL & METRIC
Hi-PerCarb
CONTINUED
131N 3xD
FRACTIONAL & METRIC SERIES
