DRILLS
DRILLS
271
www.kyocera-sgstool.com
CUTTING
DIA.
D
1
DECIMAL
EQUIV.
METRIC
EQUIV.
TAP SIZE
REFERENCE
ONLY
SHANK
DIA.
D
2
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
CLEARED
LENGTH
L
3
SHANK
LENGTH
L
4
UNCOATED
EDP NO.
Ti-NAMITE-B
(TiB
2
)
EDP NO.
15/32 0.4688 11.91
1/2-28
12,0 118,0 71,0 56,0 45,0 55026
54826
12,0 mm 0.4724
M14 X 2
12,0 118,0 71,0 56,0 45,0 65090
64890
31/64 0.4844 12.30
9/16-12
14,0 124,0 77,0 60,0 45,0 55027
54827
12,5 mm 0.4921
M14 X 1,5
14,0 124,0 77,0 60,0 45,0 65091
64891
1/2 0.5000 12.70
14,0 124,0 77,0 60,0 45,0 55028
54828
12,8 mm 0.5039
M14 X 1,25 14,0 124,0 77,0 60,0 45,0 65092
64892
13,0 mm 0.5118
M14 X 1
14,0 124,0 77,0 60,0 45,0 65093
64893
33/64 0.5156 13.10
9/16-18
14,0 124,0 77,0 60,0 45,0 55029
54829
13,5 mm 0.5315
5/8-11
14,0 124,0 77,0 60,0 45,0 65094
64894
13,8 mm 0.5433
14,0 124,0 77,0 60,0 45,0 65095
64895
14,0 mm 0.5512
M16 X 2
14,0 124,0 77,0 60,0 45,0 65096
64896
9/16 0.5625 14.29
16,0 133,0 83,0 63,0 48,0 55030
54830
14,5 mm 0.5709
M16 X 1,5
16,0 133,0 83,0 63,0 48,0 65097
64897
37/64 0.5781 14.68
5/8-18
16,0 133,0 83,0 63,0 48,0 55031
54831
14,8 mm 0.5827
16,0 133,0 83,0 63,0 48,0 65098
64898
15,0 mm 0.5906
M16 X 1
16,0 133,0 83,0 63,0 48,0 65099
64899
15,5 mm 0.6102
M18 X 2,5
16,0 133,0 83,0 63,0 48,0 65100
64900
15,8 mm 0.6220
16,0 133,0 83,0 63,0 48,0 65101
64901
5/8 0.6250 15.88
11/16-16
16,0 133,0 83,0 63,0 48,0 55032
54832
16,0 mm 0.6299
16,0 133,0 83,0 63,0 48,0 65102
64902
21/32 0.6562 16.67
3/4-10
18,0 143,0 93,0 71,0 48,0 55033
54833
11/16 0.6875 17.46
3/4-16
18,0 143,0 93,0 71,0 48,0 55034
54834
3/4 0.7500 19.05
13/16-16
20,0 153,0 101,0 77,0 50,0 55035
54835
FRACTIONAL & METRIC
Hi-PerCarb
CONTINUED
131N 5xD
FRACTIONAL & METRIC SERIES
