274 / 396
DRILLS
DRILLS
2
D
L
1
L
2
L
3
L
4
124°
30°
1
D
274
www.kyocera-sgstool.com
CUTTING
DIA.
D
1
DECIMAL
EQUIV.
METRIC
EQUIV.
TAP SIZE
REFERENCE
ONLY
SHANK
DIA.
D
2
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
CLEARED
LENGTH
L
3
SHANK
LENGTH
L
4
Ti-NAMITE-M
(TM)
EDP NO.
3,0 mm 0.1181
6,0
66,0 28,0 23,0 36,0
65160
3,1 mm 0.1220
6,0
66,0 28,0 23,0 36,0
65161
1/8
0.1250 3.18
6,0
66,0 28,0 23,0 36,0
55160
3,2 mm 0.1260
M3,5 X 0,35
6,0
66,0 28,0 23,0 36,0
65162
3,3 mm 0.1299
M4 X 0,7
6,0
66,0 28,0 23,0 36,0
65163
3,4 mm 0.1339
6,0
66,0 28,0 23,0 36,0
65164
#29
0.1360 3.45
8-32,8-36
6,0
66,0 28,0 23,0 36,0
55161
3,5 mm 0.1378
M4 X 0,5
6,0
66,0 28,0 23,0 36,0
65165
9/64 0.1406 3.57
6,0
66,0 28,0 23,0 36,0
55162
3,6 mm 0.1417
M4 X 0,35
6,0
66,0 28,0 23,0 36,0
65166
3,7 mm 0.1457
M4,5 X 0,75
6,0
66,0 28,0 23,0 36,0
65167
3,8 mm 0.1496
10-24
6,0
74,0 36,0 29,0 36,0
65168
3,9 mm 0.1535
6,0
74,0 36,0 29,0 36,0
65169
5/32 0.1562 3.97
6,0
74,0 36,0 29,0 36,0
55163
4,0 mm 0.1575
M4,5 X 0,5
6,0
74,0 36,0 29,0 36,0
65170
#21
0.1590 4.04
10-32
6,0
74,0 36,0 29,0 36,0
55164
4,1 mm 0.1614
6,0
74,0 36,0 29,0 36,0
65171
4,2 mm 0.1654
M5 / M5 x 0,75 6,0
74,0 36,0 29,0 36,0
65172
4,3 mm 0.1693
6,0
74,0 36,0 29,0 36,0
65173
11/64 0.1719 4.37
6,0
74,0 36,0 29,0 36,0
55165
4,4 mm 0.1732
12-24
6,0
74,0 36,0 29,0 36,0
65174
4,5 mm 0.1772
M5 X 0,5
6,0
74,0 36,0 29,0 36,0
65175
4,6 mm 0.1811
12-28
6,0
74,0 36,0 29,0 36,0
65176
4,7 mm 0.1850
12-32
6,0
74,0 36,0 29,0 36,0
65177
3/16 0.1875 4.76
6,0
82,0 44,0 35,0 36,0
55166
4,8 mm 0.1890
7/32-32
6,0
82,0 44,0 35,0 36,0
65178
4,9 mm 0.1929
6,0
82,0 44,0 35,0 36,0
65179
5,0 mm 0.1969
M6 X 1
6,0
82,0 44,0 35,0 36,0
65180
5,1 mm 0.2008
1/4-20
6,0
82,0 44,0 35,0 36,0
65181
13/64 0.2031 5.16
6,0
82,0 44,0 35,0 36,0
55167
5,2 mm 0.2047
M6 X 0,75
6,0
82,0 44,0 35,0 36,0
65182
5,3 mm 0.2087
6,0
82,0 44,0 35,0 36,0
65183
5,4 mm 0.2126
6,0
82,0 44,0 35,0 36,0
65184
5,5 mm 0.2165
M6 X 0,5
6,0
82,0 44,0 35,0 36,0
65185
7/32 0.2188 5.56
1/4-32
6,0
82,0 44,0 35,0 36,0
55168
5,6 mm 0.2205
6,0
82,0 44,0 35,0 36,0
65186
continued on next page
FRACTIONAL & METRIC
Hi-PerCarb
141K 5xD
FRACTIONAL & METRIC SERIES
3
• Triple margin design
improves hole stability
and size control while
providing superior
finish, roundness and
cylindricity
• Self-stabilizing pyramid
point design stabilizes
the drill on contact with
the workpiece
• Open flute structure
efficiently transports
chips while maintaining
strength at high
feed rates
• Sculpted gash allows
chips to easily flow away
from the drill center
• Recommended for
materials ≤ 400 Bhn
(≤ 43 HRc)
CAST IRON
TOLERANCES
(mm)
≤3
DIAMETER
D
1
=
+0,002/+0,012
D
2
=
h
6
>3–6
DIAMETER
D
1
=
+0,004/+0,016
D
2
=
h
6
>6–10
DIAMETER
D
1
=
+0,006/+0,021
D
2
=
h
6
>10–18
DIAMETER
D
1
=
+0,007/+0,025
D
2
=
h
6
TOLERANCES
(inch)
≤.1181
DIAMETER
D
1
=
+.00008/+.00047
D
2
=
h
6
>.1181–.2362
DIAMETER
D
1
=
+.00016/+.00063
D
2
=
h
6
>.2362–.3937
DIAMETER
D
1
=
+.00024/+.00083
D
2
=
h
6
>.3937–.7087
DIAMETER
D
1
=
+.00028/+.00098
D
2
=
h
6
>.7087–1.1811
DIAMETER
D
1
=
+.00031/+.00114
D
2
=
h
6
For patent
information visit
www.ksptpatents.com
