276 / 396
DRILLS
DRILLS
2
D
L
1
L
2
L
3
L
4
124°
30°
1
D
276
www.kyocera-sgstool.com
CUTTING
DIA.
D
1
DECIMAL
EQUIV.
METRIC
EQUIV.
TAP SIZE
REFERENCE
ONLY
SHANK
DIA.
D
2
OVERALL
LENGTH
L
1
FLUTE
LENGTH
L
2
CLEARED
LENGTH
L
3
SHANK
LENGTH
L
4
Ti-NAMITE-M
(TM)
EDP NO.
9,2 mm 0.3622
M10 X 0,75
10,0 103,0 61,0 49,0 40,0
65222
9,3 mm 0.3661
10,0 103,0 61,0 49,0 40,0
65223
U 0.3680 9.35
7/16-14
10,0 103,0 61,0 49,0 40,0
55180
9,4 mm 0.3701
10,0 103,0 61,0 49,0 40,0
65224
9,5 mm 0.3740
M11 / M10 X 0,5 10,0 103,0 61,0 49,0 40,0
65225
3/8
0.3750 9.53
10,0 103,0 61,0 49,0 40,0
55181
9,6 mm 0.3780
10,0 103,0 61,0 49,0 40,0
65226
9,7 mm 0.3819
10,0 103,0 61,0 49,0 40,0
65227
9,8 mm 0.3858
10,0 103,0 61,0 49,0 40,0
65228
9,9 mm 0.3898
10,0 103,0 61,0 49,0 40,0
65229
25/64 0.3906 9.92
7/16-20
10,0 103,0 61,0 49,0 40,0
55182
10,0 mm 0.3937
10,0 103,0 61,0 49,0 40,0
65230
10,1 mm 0.3976
12,0 118,0 71,0 56,0 45,0
65231
10,2 mm 0.4016
M12 X 1,75
12,0 118,0 71,0 56,0 45,0
65232
10,3 mm 0.4055
12,0 118,0 71,0 56,0 45,0
65233
13/32 0.4062 10.32
12,0 118,0 71,0 56,0 45,0
55183
10,4 mm 0.4094
12,0 118,0 71,0 56,0 45,0
65234
10,5 mm 0.4134
M12 X 1,5
12,0 118,0 71,0 56,0 45,0
65235
10,6 mm 0.4173
12,0 118,0 71,0 56,0 45,0
65236
10,7 mm 0.4213
12,0 118,0 71,0 56,0 45,0
65237
27/64 0.4219 10.72
1/2-13
12,0 118,0 71,0 56,0 45,0
55184
10,8 mm 0.4252
M12 X 1,25
12,0 118,0 71,0 56,0 45,0
65238
10,9 mm 0.4291
12,0 118,0 71,0 56,0 45,0
65239
11,0 mm 0.4331
M12 X 1
12,0 118,0 71,0 56,0 45,0
65240
11,1 mm 0.4370
12,0 118,0 71,0 56,0 45,0
65241
7/16 0.4375 11.11
1/4-18NPT 12,0 118,0 71,0 56,0 45,0
55185
11,2 mm 0.4409
12,0 118,0 71,0 56,0 45,0
65242
11,3 mm 0.4449
12,0 118,0 71,0 56,0 45,0
65243
11,4 mm 0.4488
12,0 118,0 71,0 56,0 45,0
65244
11,5 mm 0.4528
M12 X 0,5
12,0 118,0 71,0 56,0 45,0
65245
11,6 mm 0.4567
12,0 118,0 71,0 56,0 45,0
65246
11,7 mm 0.4606
12,0 118,0 71,0 56,0 45,0
65247
11,8 mm 0.4646
12,0 118,0 71,0 56,0 45,0
65248
11,9 mm 0.4685
12,0 118,0 71,0 56,0 45,0
65249
15/32 0.4688 11.91
1/2-28
12,0 118,0 71,0 56,0 45,0
55186
12,0 mm 0.4724
M14 X 2
12,0 118,0 71,0 56,0 45,0
65250
continued on next page
FRACTIONAL & METRIC
Hi-PerCarb
141K 5xD
FRACTIONAL & METRIC SERIES
3
• Triple margin design
improves hole stability
and size control while
providing superior
finish, roundness and
cylindricity
• Self-stabilizing pyramid
point design stabilizes
the drill on contact with
the workpiece
• Open flute structure
efficiently transports
chips while maintaining
strength at high
feed rates
• Sculpted gash allows
chips to easily flow away
from the drill center
• Recommended for
materials ≤ 400 Bhn
(≤ 43 HRc)
CAST IRON
TOLERANCES
(mm)
≤3
DIAMETER
D
1
=
+0,002/+0,012
D
2
=
h
6
>3–6
DIAMETER
D
1
=
+0,004/+0,016
D
2
=
h
6
>6–10
DIAMETER
D
1
=
+0,006/+0,021
D
2
=
h
6
>10–18
DIAMETER
D
1
=
+0,007/+0,025
D
2
=
h
6
TOLERANCES
(inch)
≤.1181
DIAMETER
D
1
=
+.00008/+.00047
D
2
=
h
6
>.1181–.2362
DIAMETER
D
1
=
+.00016/+.00063
D
2
=
h
6
>.2362–.3937
DIAMETER
D
1
=
+.00024/+.00083
D
2
=
h
6
>.3937–.7087
DIAMETER
D
1
=
+.00028/+.00098
D
2
=
h
6
>.7087–1.1811
DIAMETER
D
1
=
+.00031/+.00114
D
2
=
h
6
For patent
information visit
www.ksptpatents.com
