33 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
33
www.kyocera-sgstool.com
END MILLS
END MILLS
Z5MCR
METRIC SERIES
mm
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OFCUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
CORNER
RADIUS
R
TI-NAMITE-A
(TA)
TI-NAMITE-A
(TA)
W/FLAT
TI-NAMITE-A
(TA)
EDPNO.
W/INTERNAL
COOLANT
TI-NAMITE-M
(TM)
EDPNO.
TI-NAMITE-M
(TM)
EDPNO.
W/FLAT
TI-NAMITE-M
(TM)
EDPNO.
W/INTERNAL
COOLANT
6,0 9,0 54,0 6,0 0,5
–
–
–
47000
–
–
6,0 13,0 57,0 6,0 0,3
–
–
–
47001
–
–
6,0 13,0 57,0 6,0 0,5 47120 48002
–
47002
–
–
6,0 13,0 57,0 6,0 1,0
–
–
–
47003
–
–
6,0 13,0 57,0 6,0 1,5 48003
–
–
47004
–
–
8,0 11,0 58,0 8,0 0,5
–
–
–
47005
–
–
8,0 18,0 63,0 8,0 0,5 47121
–
–
47006
–
–
8,0 18,0 63,0 8,0 1,0 47122
–
–
47007
–
–
8,0 18,0 63,0 8,0 1,5
–
–
–
47008
–
–
8,0 18,0 63,0 8,0 2,0
–
–
–
47009
–
–
10,0 13,0 66,0 10,0 1,0
–
–
–
47010
–
–
10,0 22,0 72,0 10,0 0,5 47123
–
–
47011
–
–
10,0 22,0 72,0 10,0 1,0 47124
–
–
47012
–
–
10,0 22,0 72,0 10,0 1,5
–
–
–
47013
–
–
10,0 22,0 72,0 10,0 2,0
–
–
–
47014
–
–
10,0 22,0 72,0 10,0 2,5
–
–
–
47015
–
–
12,0 15,0 73,0 12,0 1,0
–
–
–
47016 47024
–
12,0 26,0 83,0 12,0 0,5 47125 47128 47160 47017 47025 47161
12,0 26,0 83,0 12,0 0,76 47126 47129 47162 47018 47026 47163
12,0 26,0 83,0 12,0 1,0 47127 47130 47164 47019 47027 47165
12,0 26,0 83,0 12,0 1,5 48012
–
47166 47020 47028 47167
12,0 26,0 83,0 12,0 2,0
–
–
47168 47021 47029 47169
12,0 26,0 83,0 12,0 2,5
–
–
47170 47022 47030 47171
12,0 26,0 83,0 12,0 3,0
–
–
47172 47023 47031 47173
16,0 19,0 82,0 16,0 1,0
–
–
–
47032 47039 47046
16,0 19,0 82,0 16,0 1,5 48070
–
–
–
–
–
16,0 35,0 92,0 16,0 1,0 47131
–
47134 47033 47040 47047
16,0 35,0 92,0 16,0 1,5
–
–
–
47034 47041 47048
16,0 35,0 92,0 16,0 2,0 47132
–
47135 47035 47042 47049
16,0 35,0 92,0 16,0 2,5
–
–
–
47036 47043 47050
16,0 35,0 92,0 16,0 3,0 47133
–
47136 47037 47044 47051
16,0 35,0 92,0 16,0 4,0
–
–
–
47038 47045 47052
20,0 23,0 92,0 20,0 1,0 48020
–
–
47053 47061 47069
20,0 43,0 104,0 20,0 1,0 47137
–
47140 47054 47062 47070
20,0 43,0 104,0 20,0 1,5
–
–
–
47055 47063 47071
20,0 43,0 104,0 20,0 2,0 47138
–
47141 47056 47064 47072
20,0 43,0 104,0 20,0 2,5
–
–
–
47057 47065 47073
20,0 43,0 104,0 20,0 3,0 47139
–
47142 47058 47066 47074
20,0 43,0 104,0 20,0 4,0
–
–
–
47059 47067 47075
20,0 43,0 104,0 20,0 5,0
–
–
–
47060 47068 47076
25,0 28,0 100,0 25,0 1,0
–
–
–
47077 47084 47091
25,0 53,0 121,0 25,0 1,0 47143
–
47146 47078 47085 47092
25,0 53,0 121,0 25,0 2,0 47144
–
47147 47079 47086 47093
25,0 53,0 121,0 25,0 2,5
–
–
–
47080 47087 47094
25,0 53,0 121,0 25,0 3,0 47145
–
47148 47081 47088 47095
25,0 53,0 121,0 25,0 4,0
–
–
–
47082 47089 47096
25,0 53,0 121,0 25,0 5,0
–
–
–
47083 47090 47097
METRIC
Z-Carb-HPR
• An ideal balance of
helix, indexing, flute
depth, rake and relief
• Variable indexing for
chatter supression
and proprietary edge
geometry for shearing
and strength
• Chatter-free geometry
allows deep cutting and
high speed machining
• Central coolant hole
delivers coolant
effectively to the
cutting zone enhancing
chip removal when
pocketing or slotting
• Enhanced corner
geometry with tight
tolerance corner radii
• Excels at roughing,
ramping, high speed
machining and finishing
in a variety of materials
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
≠
POS
5
2
D
1
D
L
1
L
2
37°
R
TOLERANCES
(mm)
6
DIAMETER
D
1
=
+0,000/–0,030
D
2
=
h
6
R =
+0,000/–0,050
>6–10
DIAMETER
D
1
=
+0,000/–0,040
D
2
=
h
6
R =
+0,000/–0,050
>10–25
DIAMETER
D
1
=
+0,000/–0,050
D
2
=
h
6
R =
+0,000/–0,050
For patent
information visit
www.ksptpatents.com
