36 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
36
www.kyocera-sgstool.com
END MILLS
END MILLS
Z1PCR
FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
CORNER
RADIUS
R
Ti-NAMITE-X
Ti-NAMITE-X
W/FLAT
JetStream
1/64
1/32
1-1/2
1/8
.002
36874
–
–
1/32
5/64
1-1/2
1/8
.005
36875
–
–
3/64
7/64
1-1/2
1/8
.005
36876
–
–
1/16
3/16
1-1/2
1/8
.005
36872
–
–
5/64
3/16
1-1/2
1/8
.005
36877
–
–
3/32
9/32
1-1/2
1/8
.010
36873
–
–
7/64
3/8
1-1/2
1/8
.010
36878
–
–
1/8
3/8
1-1/2
1/8
.010
36370
–
–
1/8
3/8
1-1/2
1/8
.015
36851
–
–
3/16
7/16
2
3/16
.010
36371
–
–
3/16
7/16
2
3/16
.015
36852
–
–
3/16
7/16
2
3/16
.030
36722
–
–
1/4
1/2
2-1/2
1/4
.010
36372
–
–
1/4
1/2
2-1/2
1/4
.015
36723
–
–
1/4
1/2
2-1/2
1/4
.020
36853
–
–
1/4
1/2
2-1/2
1/4
.030
36373
–
–
1/4
3/4
2-1/2
1/4
.010
36599
–
–
1/4
3/4
2-1/2
1/4
.015
36600
–
–
1/4
3/4
2-1/2
1/4
.020
36854
–
–
1/4
3/4
2-1/2
1/4
.030
36601
–
–
5/16
13/16
2-1/2
5/16
.015
36724
–
–
5/16
13/16
2-1/2
5/16
.020
36855
–
–
5/16
13/16
2-1/2
5/16
.030
36374
–
–
3/8
7/8
2-1/2
3/8
.010
36375
36701
–
3/8
7/8
2-1/2
3/8
.015
36725
36736
–
3/8
7/8
2-1/2
3/8
.020
36856
36864
–
3/8
7/8
2-1/2
3/8
.030
36376
36702
–
3/8
7/8
2-1/2
3/8
.060
36727
36738
–
continued on next page
FRACTIONAL
Z-Carb-AP
≠
≠
4
TOLERANCES
(inch)
<1/8
DIAMETER
D
1
=
+0.0005/–0.0005
D
2
=
h
6
R =
+0.000/–0.0010
1/8–1/4
DIAMETER
D
1
=
+0.000/–0.0012
D
2
=
h
6
R =
+0.000/–0.0020
>1/4–3/8
DIAMETER
D
1
=
+0.000/–0.0016
D
2
=
h
6
R =
+0.000/–0.0020
>3/8–1
DIAMETER
D
1
=
+0.000/–0.0020
D
2
=
h
6
R =
+0.000/–0.0020
• Variable rake geometry
alters and controls the
cutting dynamic taking
chatter suppression to an
unprecedented level
• Unequal helix design
changes the cutting
angle to improve
harmonics
• Unequal flute spacing
helps to disrupt the
rhythmic pattern created
by the cutting edge
helping to suppress
damaging harmonics
• Enhanced corner
geometry with tight
tolerance corner radii
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
For patent
information visit
www.ksptpatents.com
