END MILLS
END MILLS
Z1PLB
FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
REACH
L
3
Ti-NAMITE-X
1/4
1/2
4
1/4
1-1/4
36480
5/16
13/16
4
5/16
1-5/8
36482
3/8
7/8
5
3/8
1-7/8
36486
7/16
1
6
7/16
2
38490
1/2
1
6
1/2
2-1/4
38492
9/16
1-1/8
6
9/16
2-1/2
38496
5/8
1-1/4
6
5/8
3
36500
3/4
1-1/2
6
3/4
3-1/2
36502
1
1-1/2
6
1
4
36504
FRACTIONAL
Z-Carb-AP
• Variable rake geometry
alters and controls the
cutting dynamic taking
chatter suppression to
an unprecedented level
• Unequal helix design
changes the cutting
angle to improve
harmonics
• Long reach design
allows for deeper and
faster cuts
• Ball nose design ideal
for finishing operations
in complex workpieces
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
≠
≠
4
TOLERANCES
(inch)
1/4
DIAMETER
D
1
=
+0.0000/–0.0012
D
2
=
h
6
BALL RADIUS
+0.0000/–0.0006
>1/4–3/8
DIAMETER
D
1
=
+0.0000/–0.0016
D
2
=
h
6
BALL RADIUS
+0.0000/–0.0008
>3/8–1
DIAMETER
D
1
=
+0.0000/–0.0020
D
2
=
h
6
BALL RADIUS
+0.0000/–0.0010
For patent
information visit
www.ksptpatents.com
