29 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
29
www.kyocera-sgstool.com
END MILLS
END MILLS
Z5CR
FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
CORNER
RADIUS
R
TI-NAMITE-A
(TA)
TI-NAMITE-A
(TA)
W/FLAT
TI-NAMITE-A
(TA)
W/INTERNAL
COOLANT
TI-NAMITE-M
(TM)
TI-NAMITE-M
(TM)
W/ FLAT
TI-NAMITE-M
(TM)
W/INTERNAL
COOLANT
1/8 1/4 1-1/2 1/8 .015 38525
–
–
37001
–
–
1/8 3/8 1-1/2 1/8 .015 37181
–
–
37003
–
–
3/16 5/16 2 3/16 .015
–
–
–
37005
–
–
3/16 1/2 2 3/16 .015 37183
–
–
37007
–
–
1/4 3/8 2-1/2 1/4 .015
–
–
–
37009
–
–
1/4 3/8 2-1/2 1/4 .030 38528
–
–
37010
–
–
1/4 1/2 2-1/2 1/4 .015 37185
–
–
37012
–
–
1/4 1/2 2-1/2 1/4 .030 37186
–
–
37013
–
–
5/16 7/16 2-1/2 5/16 .015 38529
–
–
37015
–
–
5/16 5/8 2-1/2 5/16 .015 38530
–
–
37017
–
–
3/8 1/2 2-1/2 3/8 .015
–
–
–
37019
–
–
3/8 1/2 2-1/2 3/8 .030 38532
–
–
37020
–
–
3/8 3/4 2-1/2 3/8 .015 37188
–
–
37022
–
–
3/8 3/4 2-1/2 3/8 .030 37189
–
–
37023 37175
–
7/16 5/8 2-1/2 7/16 .015 37164
–
–
37160
–
–
7/16 5/8 2-1/2 7/16 .030 37165
–
–
37161
–
–
7/16 7/8 2-3/4 7/16 .015 37166
–
–
37162
–
–
7/16 7/8 2-3/4 7/16 .030 37167
–
–
37163
–
–
1/2 5/8 3 1/2 .015
–
38578 37330 37025 37031 37331
1/2 5/8 3 1/2 .030
–
38579 37332 37026 37032 37333
1/2 5/8 3 1/2 .060
–
38580 37334 37027 37033 37335
1/2 5/8 3 1/2 .090
–
38581 37337 37028 37034 37338
1/2 5/8 3 1/2 .120
–
–
37339 37029 37035 37340
1/2 1
3 1/2 .015
–
38583 37341 37037 37043 37342
1/2 1
3 1/2 .030 38539 38584 37343 37038 37044 37344
1/2 1
3 1/2 .060
–
38585 37345 37039 37045 37346
1/2 1
3 1/2 .090
–
–
37348 37040 37046 37349
1/2 1
3 1/2 .120
–
–
37350 37041 37047 37351
1/2 1-1/4 3-1/4 1/2 .015 37191 37195 37352 37049 37055 37353
1/2 1-1/4 3-1/4 1/2 .030 37192 37196 37354 37050 37056 37355
1/2 1-1/4 3-1/4 1/2 .060 37193 37197 37356 37051 37057 37357
1/2 1-1/4 3-1/4 1/2 .090
–
–
37359 37052 37058 37360
1/2 1-1/4 3-1/4 1/2 .120
–
–
37361 37053 37059 37362
5/8 3/4 3-1/2 5/8 .015
–
–
–
37061 37068 37261
5/8 3/4 3-1/2 5/8 .030
–
38591
–
37062 37069 37262
5/8 3/4 3-1/2 5/8 .060
–
–
–
37063 37070 37263
5/8 3/4 3-1/2 5/8 .090
–
–
–
37064 37071 37264
5/8 3/4 3-1/2 5/8 .120 38549
–
37065 37072 37265
continued on next page
FRACTIONAL
Z-Carb-HPR
• An ideal balance of
helix, indexing, flute
depth, rake and relief
• Variable indexing for
chatter supression
and proprietary edge
geometry for shearing
and strength
• Chatter-free geometry
allows deep cutting and
high speed machining
• Central coolant hole
delivers coolant
effectively to the
cutting zone enhancing
chip removal when
pocketing or slotting
• Enhanced corner
geometry with tight
tolerance corner radii
• Excels at roughing,
ramping, high speed
machining and finishing
in a variety of materials
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
≠
POS
5
TOLERANCES
(inch)
1/8–1/4
DIAMETER
D
1
=
+0.0000/–0.0012
D
2
=
h
6
R =
+0.0000/–0.0020
>1/4–3/8
DIAMETER
D
1
=
+0.0000/–0.0016
D
2
=
h
6
R =
+0.0000/–0.0020
>3/8–1
DIAMETER
D
1
=
+0.0000/–0.0020
D
2
=
h
6
R =
+0.0000/–0.0020
2
D
1
D
L
1
L
2
37°
R
For patent
information visit
www.ksptpatents.com
