STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
38
www.kyocera-sgstool.com
END MILLS
END MILLS
Z1PLC
FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
REACH
L
3
CORNER
RADIUS
R
Ti-NAMITE-X
1/4
1/2
2-1/2
1/4
1-1/8
.020
36447
1/4
1/2
3-1/2
1/4
1-5/8
.020
36448
1/4
1/2
4
1/4
1-1/4
.020
36450
1/4
1/2
4
1/4
2-1/8
.020
36449
5/16
13/16
3
5/16
1-3/8
.020
36453
5/16
13/16
4
5/16
2
.020
36454
5/16
13/16
4
5/16
1-5/8
.020
36452
3/8
7/8
3
3/8
1-5/8
.020
36457
3/8
7/8
5
3/8
1-7/8
.020
36456
3/8
7/8
4
3/8
2-3/8
.020
36458
7/16
1
6
7/16
2
.020
36460
1/2
1
4
1/2
2
.030
36463
1/2
1
5
1/2
3
.030
36464
1/2
1
6
1/2
2-1/4
.030
36462
9/16
1-1/8
6
9/16
2-1/2
.030
36466
5/8
1-1/4
5
5/8
2-1/2
.040
36468
5/8
1-1/4
6
5/8
3-3/4
.040
36469
5/8
1-1/4
6
5/8
3
.040
36470
3/4
1-1/2
6
3/4
3-1/2
.040
36472
1
1-1/2
6
1
3
.040
36475
1
1-1/2
6
1
4
.040
36474
FRACTIONAL
Z-Carb-AP
≠
≠
4
TOLERANCES
(inch)
1/4
DIAMETER
D
1
=
+0.0000/–0.0012
D
2
=
h
6
R =
+0.0000/–0.0020
>1/4–3/8
DIAMETER
D
1
=
+0.0000/–0.0016
D
2
=
h
6
R =
+0.0000/–0.0020
>3/8–1
DIAMETER
D
1
=
+0.0000/–0.0020
D
2
=
h
6
R =
+0.0000/–0.0020
• Variable rake geometry
alters and controls the
cutting dynamic taking
chatter suppression to an
unprecedented level
• Unequal helix design
changes the cutting
angle to improve
harmonics
• Unequal flute spacing
helps to disrupt the
rhythmic pattern created
by the cutting edge
helping to suppress
damaging harmonics
• Long reach design allows
for deeper and faster
cuts
• Enhanced corner
geometry with tight
tolerance corner radii
• Recommended for
materials ≤ 45 HRc
(≤ 420 Bhn)
For patent
information visit
www.ksptpatents.com
