FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
1/16
1/8
1-1/2
1/8
31701
31750
31303
31358
3/32
3/16
1-1/2
1/8
31703
31751
31304
31359
1/8
1/4
1-1/2
1/8
31705
31752
31305
31360
5/32
5/16
2
3/16
31707
31753
31306
31361
3/16
3/8
2
3/16
31709
31754
31307
31362
7/32
7/16
2
1/4
31711
31755
31308
31363
1/4
1/2
2
1/4
31713
31756
31309
31364
5/16
1/2
2
5/16
31715
31757
31310
31365
3/8
5/8
2
3/8
31717
31758
31311
31366
7/16
5/8
2-1/2
7/16
31719
31759
31312
31367
1/2
5/8
2-1/2
1/2
31721
31760
31313
31368
5/8
3/4
3
5/8
31723
31761
31314
31369
3/4
1
3
3/4
31725
31762
31315
31370
FRACTIONAL
2 Flute Square End Stub
POS
2
TOLERANCES
(inch)
D
1
=
+0.0000/–0.0020
D
2
=
h
6
