184 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
NON-FERROUS
PLASTICS/COMPOSITES
184
www.kyocera-sgstool.com
inch
EDP NO.
SERIES
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
1/64
1/32
1-1/2
1/8
30302
39302
39502
30471
3B
1/32
5/64
1-1/2
1/8
30304
39304
39504
30472
3B
3/64
7/64
1-1/2
1/8
30306
39306
39506
30473
3B
1/16
3/16
1-1/2
1/8
30308
39308
39508
30474
3B
5/64
3/16
1-1/2
1/8
30310
39310
39510
30475
3B
3/32
9/32
1-1/2
1/8
30312
39312
39512
30476
3B
7/64
3/8
1-1/2
1/8
30314
39314
39514
30477
3B
1/8
3/8
1-1/2
1/8
30378
39378
39578
30599
3B
*1/8
1/2
1-1/2
1/8
30316
39316
39516
30478
3B
1/8
3/4
2-1/4
1/8
33342
31830
31840
31890
3LB
1/8
1
3
1/8
33344
31968
31978
31988 3ELB
9/64
1/2
2
3/16
30318
39318
39518
30479
3B
5/32
1/2
2
3/16
30320
39320
39520
30480
3B
11/64
5/8
2
3/16
30322
39322
39522
30481
3B
*3/16
5/8
2
3/16
30324
39324
39524
30482
3B
3/16
3/4
2-1/2
3/16
33302
31831
31841
31891
3LB
3/16
1-1/8
3
3/16
33322
31969
31979
31989 3ELB
13/64
5/8
2-1/2
1/4
30326
39326
39526
30483
3B
7/32
5/8
2-1/2
1/4
30328
39328
39528
30484
3B
15/64
3/4
2-1/2
1/4
30330
39330
39530
30485
3B
*1/4
3/4
2-1/2
1/4
30332
39332
39532
30486
3B
1/4
1-1/8
3
1/4
33304
31832
31842
31892
3LB
1/4
1-1/2
4
1/4
33324
31970
31980
31990 3ELB
17/64
3/4
2-1/2
5/16
30334
39334
39534
30487
3B
9/32
3/4
2-1/2
5/16
30336
39336
39536
30488
3B
19/64
13/16
2-1/2
5/16
30338
39338
39538
30489
3B
*5/16
13/16
2-1/2
5/16
30340
39340
39540
30490
3B
5/16
1-1/8
3
5/16
33306
31833
31843
31893
3LB
5/16
1-5/8
4
5/16
33326
31971
31981
31991 3ELB
21/64
1
2-1/2
3/8
30342
39342
39542
30491
3B
continued on next page
FRACTIONAL
2 Flute Ball End
TOLERANCES
(inch)
D
1
=
+0.0000/–0.0020
D
2
=
h
6
BALL RADIUS
+0.0000/–0.0010
POS
2
3B
•
3LB
•
3ELB
FRACTIONAL SERIES
For patent
information visit
www.ksptpatents.com
