15
FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
1/32
1/16
1-1/2
1/8
31501
31541
39651
31316
3/64
3/32
1-1/2
1/8
31503
31543
39653
31317
1/16
1/8
1-1/2
1/8
31505
31545
39655
31318
5/64
1/8
1-1/2
1/8
31507
31547
39657
31319
3/32
3/16
1-1/2
1/8
31509
31549
39659
31320
7/64
3/16
1-1/2
1/8
31511
31551
39661
31321
*1/8
1/4
1-1/2
1/8
31513
31553
39663
31322
9/64
5/16
2
3/16
31515
31555
39665
31323
5/32
5/16
2
3/16
31517
31557
39667
31324
11/64
5/16
2
3/16
31519
31559
39669
31325
*3/16
3/8
2
3/16
31521
31561
39671
31326
13/64
1/2
2-1/2
1/4
31523
31563
39673
31327
7/32
1/2
2-1/2
1/4
31525
31565
39675
31328
15/64
1/2
2-1/2
1/4
31527
31567
39677
31329
*1/4
1/2
2-1/2
1/4
31529
31569
39679
31330
9/32
1/2
2-1/2
5/16
31531
31571
39681
31331
*5/16
1/2
2-1/2
5/16
31533
31573
39683
31332
*3/8
9/16
2-1/2
3/8
31535
31575
39685
31333
7/16
9/16
2-3/4
7/16
31537
31577
39687
31334
*1/2
5/8
3
1/2
31539
31579
39689
31335
*Series 15 Set
31589
31581
39691
31336
FRACTIONAL
2 Flute Double End Mills
TOLERANCES
(inch)
D
1
=
+0.0000/–0.0020
D
2
=
h
6
POS
2
For patent
information visit
www.ksptpatents.com
