FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
1/8
3/8
2-1/2
1/4
32280
32260
32270
3/16
9/16
3
1/4
32281
32261
32271
1/4
5/8
3-1/2
1/4
32282
32262
32272
5/16
11/16
4
5/16
32283
32263
32273
3/8
7/8
4
3/8
32284
32264
32274
1/2
1
4-1/2
1/2
32285
32265
32275
5/8
1-1/8
5
5/8
32286
32266
32276
3/4
1-3/8
5-1/4
3/4
32287
32267
32277
Neck Option Available
FRACTIONAL
2 Flute Square End Long Reach
TOLERANCES
(inch)
D
1
=
+0.0000/–0.0020
D
2
=
h
6
POS
2
For patent
information visit
www.ksptpatents.com
