182 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
NON-FERROUS
PLASTICS/COMPOSITES
182
www.kyocera-sgstool.com
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
CORNER
RADIUS
R
UNCOATED
Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
1/8*
1/2
1-1/2
1/8
.015
38201
38202
38315
38357
1/8*
1/2
1-1/2
1/8
.020
38203
38204
38316
38358
3/16*
5/8
2
3/16
.015
38209
38210
38317
38359
3/16*
5/8
2
3/16
.020
38211
38212
38318
38360
3/16*
5/8
2
3/16
.030
38213
38214
38319
38361
1/4*
3/4
2-1/2
1/4
.015
38219
38220
38320
38362
1/4*
3/4
2-1/2
1/4
.020
38221
38222
38321
38363
1/4*
3/4
2-1/2
1/4
.030
38223
38224
38322
38364
1/4*
3/4
2-1/2
1/4
.045
38225
38226
38323
38365
5/16*
13/16
2-1/2
5/16
.015
38231
38232
38324
38366
5/16*
13/16
2-1/2
5/16
.020
38233
38234
38325
38367
5/16*
13/16
2-1/2
5/16
.030
38235
38236
38326
38368
5/16*
13/16
2-1/2
5/16
.045
38237
38238
38327
38369
3/8
1
2-1/2
3/8
.015
38245
38246
38328
38370
3/8
1
2-1/2
3/8
.020
38247
38248
38329
38371
3/8
1
2-1/2
3/8
.030
38249
38250
38330
38372
3/8
1
2-1/2
3/8
.045
38251
38252
38331
38373
1/2
1
3
1/2
.015
38259
38260
38332
38374
1/2
1
3
1/2
.020
38261
38262
38333
38375
1/2
1
3
1/2
.030
38263
38264
38334
38376
1/2
1
3
1/2
.045
38265
38266
38335
38377
1/2
1
3
1/2
.060
38267
38268
38336
38378
5/8
1-1/4
3-1/2
5/8
.015
38273
38274
38337
38379
5/8
1-1/4
3-1/2
5/8
.020
38275
38276
38338
38380
5/8
1-1/4
3-1/2
5/8
.030
38277
38278
38339
38381
5/8
1-1/4
3-1/2
5/8
.045
38279
38280
38340
38382
5/8
1-1/4
3-1/2
5/8
.060
38281
38282
38341
38383
5/8
1-1/4
3-1/2
5/8
.090
38283
38284
38342
38384
3/4
1-1/2
4
3/4
.015
38287
38288
38343
38385
3/4
1-1/2
4
3/4
.020
38289
38290
38344
38386
3/4
1-1/2
4
3/4
.030
38291
38292
38345
38387
3/4
1-1/2
4
3/4
.045
38293
38294
38346
38388
3/4
1-1/2
4
3/4
.060
38295
38296
38347
38389
3/4
1-1/2
4
3/4
.090
38297
38298
38348
38390
3/4
1-1/2
4
3/4
.125
38299
38300
38349
38391
1
1-1/2
4
1
.015
38301
38302
38350
38392
1
1-1/2
4
1
.020
38303
38304
38351
38393
1
1-1/2
4
1
.030
38305
38306
38352
38394
1
1-1/2
4
1
.045
38307
38308
38353
38395
1
1-1/2
4
1
.060
38309
38310
38354
38396
1
1-1/2
4
1
.090
38311
38312
38355
38397
1
1-1/2
4
1
.125
38313
38314
38356
38398
*Without Flat
FRACTIONAL
2 Flute Corner Radius
TOLERANCES
(inch)
D
1
=
–0.0010/–0.0020
D
2
=
h
6
R =
+0.0000/–0.0020
POS
2
3CR
FRACTIONAL SERIES
