180 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
NON-FERROUS
PLASTICS/COMPOSITES
180
www.kyocera-sgstool.com
FRACTIONAL
2 Flute Square End
TOLERANCES
(inch)
D
1
=
+0.0000/–0.0020
D
2
=
h
6
POS
2
3
•
3L
•
3EL
FRACTIONAL SERIES
CONTINUED
inch
EDP NO.
SERIES
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
Di-NAMITE
®
(Diamond)
3/8
1-3/4
4
3/8
33327
31942
31952
31962
–
3EL
25/64
1
2-3/4
7/16
30349
39349
39549
30455
–
3
13/32
1
2-3/4
7/16
30351
39351
39551
30456
–
3
27/64
1
2-3/4
7/16
30353
39353
39553
30457
–
3
7/16
1
2-3/4
7/16
30355
39355
39555
30458
–
3
7/16
2
4-1/2
7/16
33309
31822
31827
31855
–
3L
7/16
3
6
7/16
33329
31943
31953
31963
–
3EL
29/64
1
3
1/2
30357
39357
39557
30459
–
3
15/32
1
3
1/2
30359
39359
39559
30460
–
3
31/64
1
3
1/2
30361
39361
39561
30461
–
3
*1/2
1
3
1/2
30363
39363
39563
30462
91290
3
1/2
2
4-1/2
1/2
33311
31806
31816
31856
–
3L
1/2
3
6
1/2
33331
31944
31954
31964
–
3EL
9/16
1-1/8
3-1/2
9/16
30365
39365
39565
30463
–
3
5/8
1-1/4
3-1/2
5/8
30367
39367
39567
30464
–
3
5/8
2-1/4
5
5/8
33313
31823
31817
31857
–
3L
5/8
3
6
5/8
33333
31945
31955
31965
–
3EL
11/16
1-3/8
4
3/4
30369
39369
39569
30465
–
3
3/4
1-1/2
4
3/4
30371
39371
39571
30466
–
3
3/4
2-1/4
5
3/4
33315
31808
31818
31858
–
3L
3/4
3
6
3/4
33335
31946
31956
31966
–
3EL
7/8
1-1/2
4
7/8
30373
39373
39573
30467
–
3
1
1-1/2
4
1
30375
39375
39575
30468
–
3
1
2-1/4
5
1
33317
31824
31819
31859
–
3L
1
3
6
1
33337
31947
31957
31967
–
3EL
*Series 3 Set
30389
39389
39589
30470
–
3
