STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
NON-FERROUS
PLASTICS/COMPOSITES
179
www.kyocera-sgstool.com
3
•
3L
•
3EL
FRACTIONAL SERIES
inch
EDP NO.
SERIES
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
Di-NAMITE
®
(Diamond)
1/64
1/32
1-1/2
1/8
30301
39301
39501
30397
–
3
1/32
5/64
1-1/2
1/8
30303
39303
39503
30398
–
3
3/64
7/64
1-1/2
1/8
30305
39305
39505
30399
–
3
1/16
3/16
1-1/2
1/8
30307
39307
39507
30400
91266
3
5/64
3/16
1-1/2
1/8
30309
39309
39509
30435
–
3
3/32
9/32
1-1/2
1/8
30311
39311
39511
30436
–
3
7/64
3/8
1-1/2
1/8
30313
39313
39513
30437
–
3
1/8
3/8
1-1/2
1/8
30377
39377
39577
30469
–
3
*1/8
1/2
1-1/2
1/8
30315
39315
39515
30438
91270
3
1/8
3/4
2-1/4
1/8
33341
31800
31810
31850
–
3L
1/8
1
3
1/8
33343
31938
31948
31958
–
3EL
9/64
1/2
2
3/16
30317
39317
39517
30439
–
3
5/32
1/2
2
3/16
30319
39319
39519
30440
–
3
11/64
5/8
2
3/16
30321
39321
39521
30441
–
3
*3/16
5/8
2
3/16
30323
39323
39523
30442
91274
3
3/16
3/4
2-1/2
3/16
33301
31820
31825
31851
–
3L
3/16
1-1/8
3
3/16
33321
31939
31949
31959
–
3EL
13/64
5/8
2-1/2
1/4
30325
39325
39525
30443
–
3
7/32
5/8
2-1/2
1/4
30327
39327
39527
30444
–
3
15/64
3/4
2-1/2
1/4
30329
39329
39529
30445
–
3
*1/4
3/4
2-1/2
1/4
30331
39331
39531
30446
91278
3
1/4
1-1/8
3
1/4
33303
31802
31812
31852
–
3L
1/4
1-1/2
4
1/4
33323
31940
31950
31960
–
3EL
17/64
3/4
2-1/2
5/16
30333
39333
39533
30447
–
3
9/32
3/4
2-1/2
5/16
30335
39335
39535
30448
–
3
19/64
13/16
2-1/2
5/16
30337
39337
39537
30449
–
3
*5/16
13/16
2-1/2
5/16
30339
39339
39539
30450
91282
3
5/16
1-1/8
3
5/16
33305
31821
31826
31853
–
3L
5/16
1-5/8
4
5/16
33325
31941
31951
31961
–
3EL
21/64
1
2-1/2
3/8
30341
39341
39541
30451
–
3
11/32
1
2-1/2
3/8
30343
39343
39543
30452
–
3
23/64
1
2-1/2
3/8
30345
39345
39545
30453
–
3
*3/8
1
2-1/2
3/8
30347
39347
39547
30454
91286
3
3/8
1-1/8
3
3/8
33307
31804
31814
31854
–
3L
continued on next page
FRACTIONAL
2 Flute Square End
POS
2
TOLERANCES
(inch)
D
1
=
+0.0000/–0.0020
D
2
=
h
6
