14
FRACTIONAL SERIES
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
1/32
1/16
1-1/2
1/8
31401
31441
39601
31170
3/64
3/32
1-1/2
1/8
31403
31443
39603
31171
1/16
1/8
1-1/2
1/8
31405
31445
39605
31172
5/64
1/8
1-1/2
1/8
31407
31447
39607
31173
3/32
3/16
1-1/2
1/8
31409
31449
39609
31174
7/64
3/16
1-1/2
1/8
31411
31451
39611
31175
*1/8
1/4
1-1/2
1/8
31413
31453
39613
31176
9/64
5/16
2
3/16
31415
31455
39615
31177
5/32
5/16
2
3/16
31417
31457
39617
31178
11/64
5/16
2
3/16
31419
31459
39619
31179
*3/16
3/8
2
3/16
31421
31461
39621
31180
13/64
1/2
2-1/2
1/4
31423
31463
39623
31181
7/32
1/2
2-1/2
1/4
31425
31465
39625
31182
15/64
1/2
2-1/2
1/4
31427
31467
39627
31183
*1/4
1/2
2-1/2
1/4
31429
31469
39629
31184
9/32
1/2
2-1/2
5/16
31431
31471
39631
31185
*5/16
1/2
2-1/2
5/16
31433
31473
39633
31186
*3/8
9/16
2-1/2
3/8
31435
31475
39635
31187
7/16
9/16
2-3/4
7/16
31437
31477
39637
31188
*1/2
5/8
3
1/2
31439
31479
39639
31189
*Series 14 Set
31489
31481
39641
31190
FRACTIONAL
4 Flute Double End Mills
POS
4
TOLERANCES
(inch)
D
1
=
+0.0000/–0.0020
D
2
=
h
6
For patent
information visit
www.ksptpatents.com
