194 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
NON-FERROUS
PLASTICS/COMPOSITES
194
www.kyocera-sgstool.com
inch
EDP NO.
SERIES
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
UNCOATED
UNCOATEDW/
FLAT
Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
Ti-NAMITE-A
(AlTiN)
W/FLAT
Di-NAMITE
®
(Diamond)
11/32 1 2-1/2 3/8
30143
–
39143
39043
30012
–
–
1
23/64 1 2-1/2 3/8
30145
–
39145
39045
30013
–
–
1
*3/8
1 2-1/2 3/8
30147
30179
39147
39047
30014
30379
91288
1
3/8 1-1/8 3
3/8
33107
–
31731
31741
31764
–
–
1L
3/8 1-3/4 4
3/8
33127
–
31864
31874
31884
–
–
1EL
25/64 1 2-3/4 7/16 30149
–
39149
39049
30015
–
–
1
13/32 1 2-3/4 7/16 30151
–
39151
39051
30016
–
–
1
27/64 1 2-3/4 7/16 30153
–
39153
39053
30017
–
–
1
7/16
1 2-3/4 7/16 30155
–
39155
39055
30018
–
–
1
7/16
2 4-1/2 7/16 33109
–
31732
31742
31765
–
–
1L
7/16
3
6
7/16 33129
–
31865
31875
31885
–
–
1EL
29/64 1
3
1/2
30157
–
39157
39057
30019
–
–
1
15/32 1
3
1/2
30159
–
39159
39059
30020
–
–
1
31/64 1
3
1/2
30161
–
39161
39061
30021
–
–
1
*1/2
1
3
1/2
30163
30180
39163
39063
30022
30380
91292
1
1/2
2 4-1/2 1/2
33111
–
31733
31743
31766
–
–
1L
1/2
3
6
1/2
33131
–
31866
31876
31886
–
–
1EL
9/16 1-1/8 3-1/2 9/16 30165
–
39165
39065
30023
–
–
1
5/8 1-1/4 3-1/2 5/8
30167
30181
39167
39067
30024
30381
–
1
5/8 2-1/4 5
5/8
33113
–
31734
31744
31767
–
–
1L
5/8
3
6
5/8
33133
–
31867
31877
31887
–
–
1EL
11/16 1-3/8 4
3/4
30169
–
39169
39069
30025
–
–
1
3/4 1-1/2 4
3/4
30171
30182
39171
39071
30026
30382
–
1
3/4 2-1/4 5
3/4
33115
–
31735
31745
31768
–
–
1L
3/4
3
6
3/4
33135
–
31868
31878
31888
–
–
1EL
7/8 1-1/2 4
7/8
30173
–
39173
39073
30027
–
–
1
1 1-1/2 4
1
30175
30183
39175
39075
30028
30383
–
1
1 2-1/4 5
1
33117
–
31736
31746
31769
–
–
1L
1
3
6
1
33137
–
31869
31879
31889
–
–
1EL
*Series 1 Set
30189
–
39189
39089
30030
–
–
1
FRACTIONAL
4 Flute End Mills
TOLERANCES
(inch)
D
1
=
+0.0000/–0.0020
D
2
=
h
6
CONTINUED
POS
4
1
•
1L
•
1EL
FRACTIONAL SERIES
