196 / 396
STEELS
STAINLESSSTEELS
CAST IRON
HIGHTEMPALLOYS
TITANIUM
HARDENEDSTEELS
NON-FERROUS
PLASTICS/COMPOSITES
196
www.kyocera-sgstool.com
inch
EDP NO.
CUTTING
DIAMETER
D
1
LENGTH
OF CUT
L
2
OVERALL
LENGTH
L
1
SHANK
DIAMETER
D
2
CORNER
RADIUS
R
UNCOATED
Ti-NAMITE
(TiN)
Ti-NAMITE-C
(TiCN)
Ti-NAMITE-A
(AlTiN)
3/4
1-1/2
4
3/4
.030
38091
38092
38145
38187
3/4
1-1/2
4
3/4
.045
38093
38094
38146
38188
3/4
1-1/2
4
3/4
.060
38095
38096
38147
38189
3/4
1-1/2
4
3/4
.090
38097
38098
38148
38190
3/4
1-1/2
4
3/4
.125
38099
38100
38149
38191
1
1-1/2
4
1
.015
38101
38102
38150
38192
1
1-1/2
4
1
.020
38103
38104
38151
38193
1
1-1/2
4
1
.030
38105
38106
38152
38194
1
1-1/2
4
1
.045
38107
38108
38153
38195
1
1-1/2
4
1
.060
38109
38110
38154
38196
1
1-1/2
4
1
.090
38111
38112
38155
38197
1
1-1/2
4
1
.125
38113
38114
38156
38198
FRACTIONAL
4 Flute Corner Radius
TOLERANCES
(inch)
D
1
=
–0.0010/–0.0020
D
2
=
h
6
R =
+0.0000/–0.0020
CONTINUED
POS
4
1CR
FRACTIONAL SERIES
